6040 5 Axis CNC With 1500W Spindle Water Pump Metal Carving Milling Router Engraver DIY Unassembled Kit

Specifications:

• Model Number: 5 Axis CNC 6040
• Work Area: 400*600*100mm
• Acceptable material thickness: 100mm
• Rack material: 12-15mm aluminum plate
• Table material: Aluminum Alloy T table + Water Tank
• Rail:

  • X&Y Axis:1605 ball Screw
  • Z Axis: 1204 ball Screw
  • Square Line Rail Track, Three-axis is 20mm square wire track
• Collet Type: ER11,1/8"(3.175mm)
• Stepper motor and drive: 57HS56
• Repeat positioning Accuracy: 0.02mm
• Communication interface: USB Port
• Power Chord: US Plug Type
• System requirements: Win-XP / Win 7 Win 8 Win10
• Software Compatibility: Mach3/Emc2/Kcam, (Type3,Wentai, ArtCAM, coppercam)
• Command code: G code/.nc/.ncc/.tab/.txt
• Product Size: 800*600*500
• Total Weight: 43kg

• Spindle motor:

  • Control: Switch control start, 6-speed transmission.
  • Voltage: 220V 50Hz
  • Power: 1500W
  • RPM: 31000RPM,
  • Spindle diameter: 64mm
  • Cooling: Air cooling
• 4th Axis:

• Centre Height: 51mm
• Maximum Turning Diameter: 81mm
• Material: 65MM cast iron 4 jaw chuck
• Decleration ratio: 1: 4 synchronous wheel drive
• Stepper Motor: 57HS56
• Weight: 3.5 kg

5th axis:

• 4th Axis Gear Ratio: 4:1 (57, 2-phase 3A stepping motor 1.2N)
• 5th axis reduction ratio: 5:1 (57, 2-phase 3A stepping motor 1.2N)
• Forgeo Chuck: 60 mm

Max Clamp:

• Forward direction: 40mm
• Reverse direction: 70mm
• 4th Axis Center Height: 55 mm
• The fifth axis is 44mm higher than the fourth axis.
• Bottom mounting hole Pitch:150 x 85 mm
• Stepper Motor: 57HS56
• Weight: 6Kg

Submersible Pump:

• Voltage: 220-240V
• Structure: Single-stage Pump
• Power: 30W
• Outlet Size: 19 mm
• Usage: Water
• Size: 90*58*75mm
• Hmax: 2.2M
• Flow rate: 2000L/H
• Weight: 0.8Kg

Applications:

• Engraving and Milling Materials:  Metal and Wood
  PCB Engraving
• Hobbyist
• Educational purpose

Frequently Asked Questions (FAQ)

• Does this CNC come fully assembled?
  No, this is a DIY kit. Mechanical assembly is mostly done, but you will need to set up the electronics, wiring, and configure the software.
• Can this machine cut steel?
  It is designed primarily for non-ferrous metals (Aluminum, Brass) and softer materials. Cutting steel is possible but very slow and not recommended for tool longevity.
• What software do I need to run this?
  Mach3 is the industry standard for these controllers. For generating G-code, you need 5-axis capable CAM software like Fusion 360.
• Is the water pump necessary for wood carving?
  Yes. Even for wood, the water cools the spindle bearings, not just the tool. Always run the pump.
• How accurate is the 5th axis?
  The rotary axes utilize reduction gears to ensure high holding torque and reasonable precision (typically 0.05mm repeatability).
• Does it support USB or Parallel port?
  Most industrial-style 6040 controllers use a Parallel (LPT) port for real-time timing. Check if a USB adapter card is included or required.
• Can I upgrade the spindle later?
  The 65mm mount is standard, but the VFD is matched to the 1.5kW motor. Upgrading power would require a new VFD and possibly a Z-axis carriage upgrade.
• What is the maximum workpiece size for 5-axis work?
  The rotary table reduces the Z-height and X/Y travel. Expect a working envelope closer to 150mm x 150mm x 100mm for full 5-axis rotation.
• Do I need to grease the rails?
  Yes, the linear bearings and ball screws should be lubricated with lithium grease every 40-50 hours of operation.
• Is technical support included for software setup?
  We provide hardware support (Probots Tech-Bridg). However, teaching complex 5-axis CAM software and Mach3 configuration is outside standard support scope.
• Can I use a laptop to control it?
  Laptops are generally discouraged due to power saving features interrupting the pulse stream. A dedicated desktop PC is best.
• What collet size does the spindle use?
  It typically uses ER11 collets. You can swap them to hold bits from 1mm up to 7mm.
• Is the bed T-slot or drilled?
  The main bed is an Aluminum T-Slot profile, allowing for versatile clamping of the rotary table or flat stock.
• How loud is this machine?
  The water-cooled spindle is very quiet. The noise primarily comes from the cutting action itself. Hearing protection is still required.
• Can it do 4-axis machining?
  Yes, you can remove the 5th axis and just use the rotary A-axis for 4-axis cylinder engraving.
• Does it include limit switches?
  Most kits include basic mechanical limit switches for homing, but wiring verification is needed during setup.
• What is the warranty period?
  Standard warranty covers manufacturing defects in the controller and spindle. Wear items like bits and bearings are excluded.
• Can I use this for PCB milling?
  Yes, the ball screws provide the precision needed for PCB isolation routing, though a higher RPM might be desired for very fine traces.
• How heavy is the package?
  The total shipping weight is approximately 85kg. It may arrive in multiple boxes.
• Does it work with GRBL?
  No, this class of machine typically uses a DSP or Mach3 controller, which is much more advanced than the GRBL based Arduino controllers.
