4240 20W Laser CNC Engraving Machine With Y axis 360° Rotary Roller & Honeycomb Plate DIY Kit US plug

Specifications:

Laser CNC:

• Product Size: 600*540*285mm
• Engraving Area: 420x400mm (maximum)
• Step motor: 42 step motor 1.3A 0.25N.M
• With Mobile App: Yes(Iklestar)
• Limit switch: Yes
• Working voltage: DC 24V, 2A
• Control Software: LaserGRBL, LightBurn
• Laser Power: 20w
• Laser Wavelength: 450 ± 5nm
• Precision: 0.01mm
• Light spot: 0.08x0.08mm
• Laser Interface: 3pin (12v, GND, PWM)
• Material: Aluminium Profile + Plastic Parts
• Compatible System: Win7/Win8/Win10/Win11/Mac/OS/Android
• Software Identification File Format: NC, BMP, JPG, PNG, G-code, Etc
• Working Environment: Temperature 5-40 ℃, Humidity 20-60%

Roller:

• Machine size: 252*205*50mm
• Package dimensions: 285*218*68mm
• Machine net weight: About 1200g
• NEMA 17 Motor: 42*34 mmRoller adjustable range (centre):20mm~122mm
• Diameter range of sculpted objects: 3mm~200mm
• Weight Capacity: 5kg

Honeycomb Panel:

• Material: Aluminium
• Diameter of table hole: 8-10mm
• The thickness of the Honeycomb Board: 22/16mm
• Dimensions include frame: 500x500x22mm


• Roller:
  • Hand-twist Knob Design & Easy to Adjust: The upgraded Y-axis rotary roller is fixed by a hand-twist knob, which is very convenient to adjust the engraving diameter. It is more trouble-free and quicker than the traditional multi-stage fixed hole-adjusted rotary axis. 20-122mm width adjustable. Engraving roller diameter: 3-200mm, which can be used for engraving different size Cylindrical Objects.
  • Engravable Objects: The laser rotary roller can engrave 360° engravings on cylindrical or round objects such as wine glasses, cola cans, round tubes, cups, bottles, pipes, bowls, drums and tubes and glass and other curved and cylindrical objects (unlimited length). The laser engraver rotary which is composed of acrylic sheet and metal material is sturdy and durable. It is smaller in size, and easy to carry.
  • Wide Compatibility: The y-axis rotary roller is compatible with most engraving machines (laser engravers, CNC router machines, etc. We have prepared 3 wirings with different wire sequences for you: white connect head wire (straight wire: 12V PWM GND), black connect head wire (cross wire: 12V GND PWM), adjustable step adapter motor wire (with wiring converter).

  • Stable, Precise, and Efficient Engraving anti-slip feet are designed to make the engraving process more stable, precise, and efficient. Stable placement, high-quality conveyor belt, rubber-wrapped rollers to increase friction, smooth operation, and placement of cylindrical objects can achieve 360-degree rotation engraving.
  • Pre-assembled & With Wine Glass Holder: The accessories are fully assembled, there is no complicated assembly, and you can use it simply by connecting the Y-axis cable port of the engraving machine. The wine glass holder supports the wine glass for engraving, so you can unleash your creativity. There are detailed and clear instructions and wiring in the package. If you encounter any problems during use, please feel free to contact us.
• Honeycomb Panel:


  • • Protective accessories for laser cutting: After using this laser cutting honeycomb table to cut wood, acrylic, and other materials, the edges of the wood are neat and clean, not easy to be yellowed by smoke, and you can get a clean cutting work.
    • Cutting through observable design: The honeycomb table contains a very convenient cutting and observation design. When the laser cuts through wood or acrylic, the metal plate at the bottom of the honeycomb will emit a bright light, which means that the cutting has penetrated. Solve the problem that an ordinary engraving machine is difficult to judge whether cutting through.
    • Safe metal desktop protection board: The honeycomb Board is equipped with a metal desktop protection board, which can protect the table from laser damage, which is very suitable for many different diode laser engravers.
    • Wide compatibility: The machine can be compatible with various mature laser engraving machines.
    • All-metal high flatness: processed by high-precision CNC, solid structure not easy to deform, and high flatness.

Applications:

• Engraving Materials: Wood, Leather, Paper, Acrylic, Plywood, Glass, Stainless Steel or other Soft Metal and so on.
• Cutting Material: Wood, acrylic, cardboard, fabric, bamboo, plastic board, KT board

Frequently Asked Questions (Technical FAQ)

• What is the difference between 20W and 5W output?
  The "20W" refers to the electrical power consumption. The "5W" is the actual optical power of the laser beam, which determines cutting capability.
• Can this machine cut clear acrylic?
  No, diode lasers (450nm blue light) pass through clear acrylic. You can only cut opaque, black, or colored acrylic.
• How thick of plywood can this cut?
  It can comfortably cut 3mm birch plywood in 1 pass, and up to 5-6mm in multiple passes with proper focus.
• Do I need to assemble the rotary roller?
  The rotary roller usually comes preassembled but requires wiring into the Y-axis stepper port on the mainboard.
• Does it work with LightBurn software?
  Yes, it is fully compatible with LightBurn (GRBL controller profile), which is the industry standard for laser control.
• How do I connect the Rotary Roller?
  Unplug the Y-axis motor cable from the motherboard and plug in the Rotary Roller cable instead.
• Can it engrave on metal?
  It can engrave on coated metal (like anodized aluminum) or painted steel. It cannot engrave bare, reflective metals like raw silver or gold.
• What is the purpose of the Honeycomb plate?
  It supports the material while allowing smoke and laser beams to pass through, preventing burn marks on the back of your workpiece.
• Is the firmware open source?
  It runs on GRBL 1.1, which is open-source. You can flash standard GRBL firmware if needed.
• Does it support offline engraving?
  Yes, the controller typically has a TF/SD card slot for offline operation if you export the G-code file.
• How long can the laser run continuously?
  We recommend a duty cycle of 30-45 minutes on, followed by a cool-down, though active cooling fans allow longer runs.
• Can I upgrade the laser module later?
  Yes, the mount is standard. You can upgrade to a 10W or 20W optical module later if you need more cutting power.
• What maintenance does it need?
  Clean the laser lens with a Q-tip and isopropyl alcohol every 10 hours of use to prevent smoke residue from cracking the lens.
• Does it come with a power supply?
  Yes, a 24V DC power adapter (US Plug style, may need adapter) is included.
• Is it compatible with Mac OS?
  Yes, via LightBurn software. LaserGRBL is Windows only.
• How do I adjust the Z-axis?
  The laser module has a thumbscrew slide. Loosen it, place the focus spacer, and tighten it back down.
• Can it cut leather?
  Yes, it cuts thin leather easily. Be aware it produces a strong smell; ventilation is mandatory.
• What is the maximum engraving speed?
  It can travel up to 10,000mm/min, but optimal engraving speeds are usually between 1000-3000mm/min depending on material.
• Does it have limit switches?
  Yes, X and Y limit switches are included to allow for "Homing" the machine.
• Is technical support available if I get stuck?
  Absolutely. With Probots Tech-Bridge™, you get access to our local Bangalore engineers who understand GRBL and laser settings.

      Package List:

• 1 x 4240 Unassembled Laser Engraver
• 1 x Control Board (with limit switches and Bluetooth)
• 1 x Power Supply
• 1 x Focus plate
• 1 x USB stick
• 1 x Product manual
• 1 x 20W laser Module
• 1 x Y-axis Rotary roller1 x Honeycomb panel
• 4 x Test Planks
• 2 x Stainless Steel Test Plates
