4540 3-Axis CNC with 500W Spindle & 40W Laser - DIY Router Engraver Kit

Specifications

• Working Area: 430 x 390 x 90 mm (16.9 x 15.4 x 3.5 inches)

• Spindle: 500W DC Spindle (0-11,000 RPM) with adjustable PWM

• Laser Module: 40W Output (10W Optical) with 450nm wavelength

• Accuracy: 0.01mm mechanical precision; ~0.1mm repeat positioning

• Stepper Motors: NEMA 17 (42 x 48mm)

• Control Method: Computer (USB) or Touchscreen Offline Controller

• Software Compatibility: GRBL Control (Candle), LaserGRBL, LightBurn

• Material Support: Aluminum 6061, Brass, Copper, Stainless Steel (light), Wood, Acrylic, MDF, PCB

Key Applications & Projects

• Custom Signage: Carve intricate patterns into wood or acrylic with the 500W spindle.

• Metalworking: Engrave or mill soft metals like 6061 aluminum and brass for industrial parts.

• PCB Prototyping: Mill precise circuit board traces with the sharp 0.1mm engraving bits.

• Personalized Gifts: Rapidly laser engrave leather wallets, phone cases, or wooden plaques.

Unlock New Capabilities (Project Evolution)

• Feature Upgrade: The integrated Z-Probe simplifies the tool-setting process, automatically detecting the material height to ensure perfect depth on every carve.

• Effort Level: Intermediate DIY. While main components are pre-assembled, full setup and software learning typically take 15-30 minutes.

Package Includes:

• 1 x 4540 CNC Mainframe DIY Kit

• 1 x 500W DC Air-Cooled Spindle

• 1 x 40W Compressed Spot Laser Module

• 1 x 2.8" Touchscreen Offline Controller

• 1 x Integrated Control Box (48V Power Supply & GRBL Board)

• 1 x Z-Probe Tool Setting Sensor

• 10 x Sharp V-Shaped Engraving Bits

• 1 x 2G USB Disk (Manuals & Software)

• 4 x Workpiece Clamps

FREQUENTLY ASKED QUESTIONS (FAQ)

1. Can this machine cut through 6061 Aluminum? Yes, with the 500W spindle it can mill aluminum. Recommended pass depth is 0.1-0.5mm with appropriate feed rates.

2. Is it a complete DIY kit or pre-assembled? The main XY and Z modules are pre-assembled; users only need to connect the modules and wire the controller.

3. What software should I use? It uses GRBL-based software like Candle for milling and LaserGRBL or LightBurn for laser tasks.

4. Does the 40W laser require goggles? The module includes an eye-protection cover, but wearing safety goggles is always recommended during operation.

5. Can I use the laser and spindle at the same time? No, they share the same control port and should be used one at a time for their respective tasks.

6. What is the "Z-Probe" used for? It allows the machine to electronically sense the material surface, making it easy to set the "Z-zero" point.

7. Will it work on a Mac? Yes, the GRBL controller is compatible with Windows XP/7/10/11 and Mac OS via UGS.

8. Can I engrave on stainless steel with the laser? Yes, the 40W module (10W optical) is powerful enough for light engraving on stainless steel and anodized aluminum.

9. What happens if I exceed the engraving range? The machine is equipped with limit switches on both ends of the X, Y, and Z axes to stop movement and prevent damage.

10. How do I transfer files to the offline controller? Save your G-code to the included SD card, insert it into the controller, and select the file from the touchscreen.

11. Is the spindle speed adjustable? Yes, the spindle supports 0-100% PWM speed adjustment via software.

12. Do I need to add oil when engraving metal? Yes, lubricating oil is highly recommended to reduce friction and keep the material cool during metal milling.

13. What is the maximum travel speed? The machine can move at a maximum speed of 5000 mm/min.

14. How long does assembly take? For most users, assembly and initial wiring take between 15 and 30 minutes.

15. Does it support a 4th axis? The standard board is a 3-axis controller; 4-axis support would require a board upgrade.

16. Is it suitable for total beginners? CNC operation involves a learning curve in design software (CAD/CAM). We recommend utilizing community tutorials for the software part.

17. What is the optical power of the 40W laser? It has a 10W optical output power, which is the actual laser energy hitting the surface.

18. Can I cut acrylic with the laser? Yes, it can cut dark-colored acrylic up to 3-5mm thick.

19. What size are the stepper motors? It uses high-torque NEMA 17 stepper motors with a 48mm length.

20. Is there an emergency stop? Yes, a dedicated emergency stop button is integrated into the control box for immediate shutdown.
