Multifunction Shield Arduino Uno / Leonardo
This Multifunction Shield For Arduino Uno / Leonardo is all one shield for beginner users of the Arduino Development Board. This Arduino Uno and Leonardo compatible multifunction shield have a large range of features which makes it ideal for beginners who just want to experiment and learn, or just as a general-purpose shield for more advanced uses.
Building some creative and simple projects is a great way to walk through coding and basic electronic circuits knowledge. This board is of great use to beginners who are new to coding and into the field of electronics. These Arduino and Leonardo shields help them to control LEDs, read switch inputs from the switches available on the board and displaying decimal numbers on the 7-segment display, which are all the basics needed for them to get started
Besides the feature-rich range of components fitted to the shield, there is also a range of expansion headers for the convenient interfacing of external modules and components. The shield includes R3 type headers for easy connection to your Arduino board.
Before applying power to your Arduino board check that other than the header pins, none of the pins from the bottom side of this shield is in contact with the host board.
- 4 digit 7-segment LED display module driven by two serial 74HC595’s.
- 4 x surface mount LED’s in a parallel configuration.
- 10K adjustable precision potentiometer.
- 3 x Independent push buttons.
- Piezo buzzer.
- DS18B20 temperature sensor interface.
- LM35 temperature sensor interface.
- Infrared receiver interface.
- Serial interface header for convenient connection to serial modules such as Bluetooth, a wireless interface, voice module, a voice recognition module, etc.
1 x Multifunction Shield For Arduino Uno / Leonardo.
