Read Article βThe XYS3580 power supply is a buck-boost structure that integrates analog adjustment and digital control and can view data such as preset voltage / current, input voltage/ output voltage/ current/power Icapacity Ienergy/ run time in real time.Β
XYS3580 power supply is a DC voltage Buck-Boost panel mount converter, which integrates analog adjustment and digital control. It can view the preset voltage, current, input voltage, output voltage, current and power capacity, operation time, and other data in real time. When the input voltage is lower than or equal to or higher than the output voltage, the output voltage can be stable!
It features over-voltage protection, over-current protection, over-power protection, low-voltage protection, over-temperature protection, reverse protection, and short circuit protection, and also with 1.44 inch HD LCD, one screen displays voltage/current/power and other data, 160° wide viewing angle with high brightness, it is designed for panel mount and with its small size, simple operation, high precision, stable performance, make a wide range of use!
This XYS3580 DC-DC Adjustable Buck Boost Converter widely used as a common voltage Buck-Boost power supply with over-voltage, over-current, over power, over temperature, and under voltage protection, With its constant current function, can be used to charge the rechargeable battery within 0.6V~36V and also can directly drive 0.6-30V, 0-15W LED lamp
Note: To gain the rated full load output power, the input power supply must be to the rated input value.,ie The lower the input voltage the lower the output power
Downloads:
Features:
Package includes:
Specifications:


| Technical Details |
|
|---|---|
| Module Function: | Buck-Boost (Step Up & Down) |
| Input Voltage (Min): | 6 V |
| Input Voltage (Max): | 36 V |
| Output Voltage (Min): | 0.6 V |
| Output Voltage (Max): | 36 V |
| Maximum Power: | 80 W |
| Max Current: | 5 A |
| Regulation Mode: | Switching CC/CV |
| Display: | Yes |
