ZMCT103C 5A AC Current Transformer Sensor Breakout

₹149.00 Rs. 126.27 + 22.73 GST
ZMCT103C is a hall effect transformer for measure AC Current. Great for building AC current sensing, energy monitors, loggers, home automation systems, etc
In stock. 1-7 Day Delivery in India.
SKU
PRO2190

ZMCT103C is a hall effect transformer for measure AC Current. This module uses the transformer to convert AC Mains Current to a small measurable current in the ratio 1000:1. Great for building AC current sensing, energy monitors, loggers, home automation systems, etc

The transformers 2 output pins which output the low current signal are broken out to 2 header pins which can be easily connected to an external circuit. Using a simple current to voltage converter, you can then connect the output to a microcontroller to measure the AC Current.

Note: We have a plug and play model of this current sensor with all required external electronics included. You can use this module to directly convert AC current to a 0-5V Voltage signal. You can check it out here - ZMCT103C 5A AC Current Sensor Transformer Module

Features :

  • Onboard precision microcurrent transformer.
  • Onboard sampling resistor.
  • The module can measure AC currents less than 5A, the corresponding analog output 5A/5mA.
  • Onboard precision microcurrent transformer.
  • Onboard sampling resistor.
  • Rated input current: 5A
  • Rated output current: 5mA
  • Ratio: 1000: 1
  • The linear range: 0 ~ 10A (100 ohms)
  • Linearity: 0.2%

Applications

  • Current, Power, And Energy Monitoring Device
  • Current Measurement
  • Precision Power Meter
  • Great for building AC current sensing, energy monitors, loggers, home automation systems, etc

Package Includes :

1 x Single-Phase AC Current Sensor Module (5A )
