STM32F103C8T6 Development Board ARM Cortex M3 STM32

₹599.00 ₹ 507.63 + 91.37 GST
In stock
SKU
PRO770

The STM32F103C8T6 is a great development board to get started with STM Development. Can be programmed through Arduino IDE.

Note: There are many fake versions of this module available for a much cheaper price. They use low-cost IC's onboard which are unreliable and may not work. They fail to detect on computers and you will encounter programming issues. Each board we sell are tested for proper working and are souced from the best available suppliers.

We also have the same board with the STM32F103C6T6 Microcontroller. It comes with lower flash memory(32KB) and less SPI, I2C Ports, etc at lower cost. Check it out here.

The STM32F103C8T6 is a great development board to get started with STM Development. It is an entry level low cost microcontroller but very capable in speed and performance. Similar to the Arduino but much more powerfull. Can be programmed through Arduino IDE to make use of the Arduino IDE, Libraries and Software.

This board is compatible with the popular Blue Pill Development Board.

Features

  • This board is very suitable for learners that want to learn STM32 microcontroller with ARM Coretex-M3 32-bit core.
  • On-board SWD interface, and it can be programmed with ST-LINK V2.
  • On-board reset button and power indicator LED.
  • On-board test indicator LED, and the beginners can program to control it.
  • On-board 100mA 3.3V Regulator.
  • All GPIO are led out and the names of the pins are marked
  • Operating voltage: 3.3 V.
  • IO logic voltage: 3.3V
  • Digital I/O Pins: 37.
  • Analog Input Pins: 10 (12bits).
  • USB interface:1
  • Flash Memory: 64KB.
  • SRAM: 20KB.
  • Programmable Clock Speed: 72 MHz (MAX).
  • Model: STM32F103C8T6
  • Core: ARM 32 Cortex-M3 CPU.
  • Debug mode: SWD.
  • 72MHz work frequency.
  • 64K flash memory,
  • 2.0-3.6V power, I/O.
  • Reset(POR/PDR).
  • 4-16MHz crystal.
  • On-board Mini USB interface, you can give the board power supply and USB communication.
  • Size: Approx. 55*20*10mm



Package Includes:

  • 1x STM32 ARM Minimum System Board
More Information
Technical Details

The STM32F103C8T6 can be programmed through -

  • USB to Serial Converter: Using a FTDI Adapter or a generic USB to Serial Converter.
  • STLink Programmer
  • Onboard USB: The board can be programmed through the onboard USB after uploading a USB Bootloader usiing one of the above 2 methods.

Programming IDE -

  • Arduino IDE
  • STM32Cube

Product Page: Specs & Documentation
