ProMax PST16240OL Push Button Latching Switch Round 240V Orange Indicator Light

ProMax PST16240OL-11C Push Button Switch is an Industrial Grade switch for consumer, industrial, medical products, and generic applications. Designed to work in harsh conditions and environments. Manufactured as best in class power ratings, build quality, and operation life.

The switch comes with inbuilt LEDs for status indication. Perfect for offering a neat user interface and clear operation. The switch led can be controlled through 2 pins. The Indication LED can be wired to light up when the switch is closed and turn off when the switch is open.

Compared to metal switches, switches built with a Plastic body, offer some inherent advantages & are preferred for their - resistance to corrosion in harsh chemical environments and high insulation resistance during operation. ProMax PS16 switches are specifically manufactured to offer the best in Resistance to Chemical Environments Like Salts (Sea and Roads)Harbours, Marine, Aggressive vapors Oil & Gas, Wood & Paper Industries, Water Treatment Plants, etc.

Features

• Brand: ProMax
• Model: PST16240OL-11C
• The switch can be used to control load directly or as input to Microcontroller / PLC / Contactor, etc
• Panel Mounting for easy installation in Industrial Control Panel & Enclosures. Offers professional finish after mounting
• Pin Terminals are Crimp type for easy wiring. Wires can also be soldered directly
• Switch No. of Poles: 1 Pole with Common, NO and NC Contacts
• Switch Operation Type: Latching
• LED Illumination Color: Orange
• Switch Thread Diameter: 16mm
• LED Operating Voltage: 240V AC/DC
• Max Load Switching Voltage: 300V AC, 100V DC
• Max Load Switching Current: 3A @ 240V AC, 0.5A @ 24V DC
• Ingression Protection Rating: IP40
• Minimal Electrical Noise during switching
• Switch Operating Cycles MTBF: 50,000 cycles
• LED Minimum Life: 50,000 working hours

Applications

• Perfect Replacement for traditional switches where switch status is to be indicated to users
• Can be used as Power Switch for Load Control. Add a contactor for loads beyond the output capacity of the switch.
• Can be used as Start / Stop / Reset or a Generic Input Switch
• Automobile Dashboards and Panels. Consumer & Medical Products
• Industrial Control Panels. Elevator, Lift, Crane Controls
• Generic System start/stop applications. Emergency Stop Switches
• Suitable for generic load switch and switch status indication
