ProMax BCR75 Barcode QR Code Scanner Module with USB UART Interface GM75

₹3,499.00 ₹ 2965.25 + 533.75 GST
In stock
SKU
PRO3194

Industrial Grade Barcode QR Code Reader. Reads codes directly outputs the data over Serial UART and USB. Can be directly connected to microcontroller (Arduino, ESP32, Raspberry Pi, etc) and PLC.

ProMax BCR75 is a high-performance industrial grade, scanner that can read multiple types of 1D & 2D codes. It offers high scan speeds, easy wiring and interface, surface mount mountings and inbuilt light for illuminating the QR Code.

Just point the scanner to a code and the data in the code will be sent out through the serial interface. USB HID interface lets the scanner output the code directly through USB. It detects as a keyboard and code data will be entered directly to any software that takes input from keyboard - Excel, Word, Browser, Billing Software, etc

Applications

  • This barcode scanner is specifically suitable for high performance applications where high speed objects and low light operations is required
  • Suitable for Installation in low illumination Areas. Inbuilt White Light is provided to illuminate the code when dark. This makes it suitable for use in  Parking at Basements, Access Control, etc
  • High Scan Speed supports scanning of fast moving objects. Suitable for assembly line, production, shopping mall billing counters, etc
  • Ticket Scanning, Access Control, Events, Travel, and Movies
  • Advertising, Games, Tracking products, Inventory Management, etc

Specifications:

  • Can detect the following codes -
    • 1D: EAN-13, EAN-8, UPC-A, UPC-EM ISSN, ISBN, CodaBar, Code 128, Code93, ITF-14, ITF-6, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, GS1 Databar(RSS), Code 39,Code 11, MSI-Plessey, etc
    • 2D: QR Code, Data Matrix, PDF417, Micro PDF417, Micro QR, Aztec,etc
  • Offers plug and play feature for projects that require barcode scanners. All image processing algorithms and codes are inbuilt. Users need not worry about developing these low level features and can directly use this module in their application.
  • Supports Two Output Options - UART and USB
  • UART can be used to connect the scanner to a microcontroller or PLC. Code data is processed, decrypted and transmitted through Serial Tx line
  • When connected through USB, the scanner shows up as HID Keyboard. Code data is outputted into any software - Excel, Word, Browser, Billing Softwares, etc
  • Image exposure, contrast, lighting level can be set. Capable for scanning coded moving at high speeds upto 20cm/s
  • Inbuilt Buzzer offers status indication
  • High-precision small code reading (1D: 3mil, 2D: 5mil)
  • High-speed reading allows scanning codes on high speed objects
  • High-contrast reading allows scanning codes in low light conditions, codes with less contrast between background
  • Easy to install with surface mount provisions on the body
  • Green Collimation Light Available for alignment of code and scanner
  • Optical Resolution: 640*480dpi
  • Scan Breadth: A4
  • Scan Speed: 20cm/s
  • Interface Type: USB, Serial UART(5V Logic)
  • Operating Voltage: 5V
  • Operating Current: 250mA(Max)
  • Size: 53*49*23.7mm
  • Weight: 31.3g
  • Lighting: White Light (3000K)
  • Collimation: Green Light (527nm)
  • Reading Distance: upto 40cm
  • Contrast: ≥15%
