2216 500KV Waterproof Thruster With 60mm Propeller RC Boat Motor CC W With 30A ESC

Features:

• Exquisite workmanship and high-quality materials ensure long service life and higher work efficiency.
• The blade is made of ABS and PC injection mold with high precision and stable performance.
• Metal and electronic parts materials are manufactured to ensure maximum durability.
• Proprietary unique, complete waterproof process: the motor is fully potted and corrosion and oxidation resistant.
• High-quality bearings: the motor is equipped with precision bearings, which significantly improve the engine's service life.
• Super endurance and stable working: 100m-300m underwater.

Applications:

• Subsurface equipment
• Underwater blade thruster
• ROV underwater robot
• Electric surfboard
• Electric trawler

Package Includes:

• 1 X 2216 500KV Waterproof Thruster With 60mm Propeller RC Boat Motor CW With 30A ESC

Frequently Asked Questions

• Can I control this thruster with an Arduino or ESP32?
  Yes, the included 30A ESC accepts standard 50Hz PWM signals, so you can control it easily using the standard Servo library on most microcontrollers.

• Is this motor safe for saltwater environments?
  The motor is fully sealed and safe for submerged marine use, but we highly recommend rinsing it thoroughly with fresh water after saltwater exposure to prevent long-term corrosion.

• What voltage does this thruster setup require?
  The 30A ESC is designed to operate between 11.1V and 16.8V, making it perfectly suited for 3S or 4S LiPo battery packs.

• How much current does the motor draw at full throttle?
  Under heavy load in the water, the motor can draw up to 30A continuously, which is why a high-discharge LiPo battery is strictly required.

• How do I reverse the rotation direction of the motor?
  If the motor spins in the wrong direction, simply disconnect and swap any two of the three thick wires connecting the motor to the ESC.

• How do I connect the ESC to my RC receiver?
  Plug the 3-wire servo connector (White/Red/Black) from the ESC directly into the throttle channel (usually CH3) of your RC receiver.

• Which Arduino library should I use for this ESC?
  You do not need a specialized library; the standard #include <Servo.h> library works perfectly to generate the required throttle signals.

• Is there a MicroPython way to control this?
  Yes, you can use the machine.PWM module on platforms like the Raspberry Pi Pico or ESP32 to generate the 50Hz signal (1000µs to 2000µs pulse width).


Specification:

• Model: 2216
• Kv: 500
• Voltage: 12
• Load Current: 7.3
• No Load Current: 0.3
• No Load Speed: 6100
• Power: 87 w
• Direction: CCW
• Lipo Cell: 12-16v
• Thrust: 1.2kg @ 8A
• High Speed: 6000
• Waterproof depth: 300m
• Material: Metal, ABS
• Dimension(DxH):28x38.5mm
• Color: Black and Blue
• ESC:

  • Current Rating: 30A
  • Operating Voltage: 12V-24V
  • Lipo Cell :2-4S
• Propeller Blade:

  • Material: ABS.
  • Color: Blue
  • Height: Approx. 30mm / 1.2in
  • Inner Diameter: Approx. 28mm / 1.1in
  • Outer diameter: Approx. 60mm / 2.4in
  • Diameter: Approx. 60mm / 2.4in
  • Fixing screw: M3 x 2
