Read Article →Waterproof High Torque Servo Motor with Metal Gears. Suitable for building robot arms, grippers, rc planes, rc cars, gimbals, etc
Servo Motors are great for applications where output positional control is required. These servos rotate between 0 and 180 degrees only. The shaft can be moved to any required angle using a PPM signal. Servo motors are the easiest-to-use motors as they do not require external motor drivers, feedback sensors, etc. Just connect it to your microcontroller to a Digital IO pin and you can start controlling the servo motor.
The DS3218 is a high-quality servo motor and generates torque up to 20kgs. Suitable for high torque applications like Robot Arms, Grippers, Controlling Flaps in RC Planes, Steering Control in RC Cars, or as a generic mechanical actuator.
The Improved DS3218 PRO Model comes with higher torque and speed compared to the standard DS3218 Servo. These servos come with metal gear and waterproof construction. They are IP66 rated for water and dust protection.
Features:
Model: DS3218 Pro 20KG. The Pro model can deliver upto 23kgs of torque @ 6.8V
Operating Voltage: 4.8 ~ 6.8V DC
CNC aluminum middle Shell for IP66 Protection from Water & Dust
Dual ball bearings for smooth operation and long life
High-performance digital standard servo offers higher accuracy compared to standard servos
High-precision metal gears with hard anodizing for high-torque applications
Torque Digital Servo Stall Torque (5V): 21 kg/cm (263.8oz/in)
Stall Torque (6.8V): 23 kg/cm (298.5 oz/in)
Speed : 0.12 sec/60°(5V) / 0.1 sec/60°(6.8V)
Signal Dead Band: 3μs
Weight: 60 g (2.12 oz)
Motor Type: DC Motor
Gear Type: Copper & Aluminum
Working frequency: 1520μs / 333hz
Size: 40 x 20 x 40.5 mm ( 1.58 x 0.79 x 1.60 in)
Package Includes:
1 x DS3218 20KG Large Torque Digital Servo
1 x 25T Adjustable metal servo arm
ALL PICTURES SHOWN ARE FOR ILLUSTRATION PURPOSES ONLY

| Technical Details |
Probots DS3218 Pro Servo Motor Dimensions
Probots DS3218 Pro Servo Motor Control |
|---|---|
| Operating Voltage: | 4.8 V - 6.0 V |
| Holding Torque: | 20 kg-cm |
| Rotation Angle: | 180 Degrees |
| Gear Material: | Metal |
