XT30 Female Connector with 16AWG High Temp Silicone Wire Pigtail - 10cm

Specifications

• Connector Type: XT30 Female (Socket) - Battery Side

• Wire Gauge: 16AWG (Standard for XT30)

• Wire Length: 10 cm

• Insulation: Soft Silicone (200°C Rated)

• Conductor: Tinned Copper

• Rated Current: 30A Continuous / 40A Burst

• Housing Material: High-Temp Nylon

Key Applications & Projects

• Battery Repair: Replace damaged connectors on Tattu, GNB, or CNHL micro batteries.

• Charging Leads: Build custom charge cables for your specific charger setup.

• Power Distribution: Use as a power input socket on your custom PCB projects.

Unlock New Capabilities (Project Evolution)

• Prerequisites: A damaged battery or a custom power project.

• Feature Upgrade: Switching from JST-PH (red) connectors to XT30 massively reduces resistance, giving your micro-drone more punch and longer flight times.

• Effort Level: Intermediate. Splicing battery wires requires caution (do one wire at a time!).

Virtual Technician & Wiring

• ⚠️ DANGER: When replacing a battery connector, NEVER cut both wires at the same time. You will short the battery. Cut, solder, and shrink-wrap one wire completely before touching the second one.

• Polarity:

  • Flat Side: Red (+) Positive

  • Round/Chamfered Side: Black (-) Negative

Accessories & Parts

What's Included:

• 1 x XT30 Female Connector with 10cm 16AWG Silicone Wire

Required Alternatives:

• For Drone Side: You need the XT30 Male Pigtail.

• Insulation: 3mm Heat Shrink Tubing is essential for battery repairs.

Frequently Asked Questions (FAQ)

1. Is this the one for the battery? Yes, Female (Recessed Pins) = Battery Side.

2. Will this fit my 450mAh battery? Yes, perfect for 450mAh - 1500mAh packs.

3. Is 16AWG too thick? No, 16AWG is the standard size for XT30. It fits perfectly.

4. Can I use this on a 3S battery? Yes, works for 2S, 3S, 4S LiPos.

5. Is the wire silicone? Yes, high-quality soft silicone.

6. Are the ends pre-tinned? Yes.

7. Is it waterproof? No.

8. Does it come with a cap? No cap included.

9. What is the max current? 30 Amps continuous.

10. Is this compatible with XT60? No, XT30 is much smaller.

11. Can I use crimping? No, these are solder-type connectors.

12. Is the housing heat resistant? Yes, Nylon housing resists melting during soldering.

13. Why use 16AWG? It matches the XT30 current rating perfectly without adding unnecessary weight.

14. Can I use this for solar panels? For small, portable panels (<5A), yes.

15. Is polarity marked? Yes, on the side of the connector.

16. How do I insulate the joint? Use heat shrink tubing over the solder splice.

17. Can I use this for audio? Yes, as a quick disconnect.

18. Is the wire copper? Yes, Tinned Copper.

19. Will it fit genuine Amass plugs? Yes, fully compatible.

20. Can I shorten the wire? Yes, cut to desired length.
