AMP Series Connectors Kit

AMP Connectors | AMP Plugs | AMP Sockets

These high-power, environmentally sealed AMP connectors for harsh-environment wire-to-wire connections are designed to withstand the extreme operating conditions of applications in the trucking, agricultural, mining, construction, and marine industries. The series is constructed of heavy-duty, shock- and vibration-resistant thermoplastic, employs the company’s field-proven contacts, which are rated for 10A , has a slide lock for easy mating and confirms contact alignment and retention, and is available with IP68 protection against dust, dirt, and moisture.

This is an assorted kit of regularly used AMP connectors from 2 Pin to 4Pin. It comes with compatible crimp pins which can be used to make your own custom cables and harness.

AMP Superseal plug housings are designed for cable to cable connections. Their seals provide a robust seal with a high degree of environmental protection. Safe, versatile and reliable, AMP connector housings are made from a thermoplastic which is ideal for automotive applications. You will not struggle for choice as the AMP plugs are available in 12 to 4 pin options. The housings feature an integrated latch for mating.

AMP series connectors will stand up to the harsh environmental challenges that are common to industrial markets and require advanced performance. Proper parts, procedures, and tooling must be used and we have taken utmost care to select the best quality manufacturers.

Features

• Maximum Rated Voltage: 300V
• Nominal Current: 10A
• Sturdy and reliable contacts: their lanceless design eliminates contact tangling during handling operations.
• Double contact spring: mainspring and auxiliary anti-overstress spring.
• Preassembled lock which ensures correct and complete insertion of the contact in the housing and prevents it from slipping out of the connector. The lock cannot be closed if the contact is not correctly inserted in the housing
• The AMP SUPERSEAL Series connectors are completely interchangeable
• Both plug and receptacle have a collar to fit additional protective caps if required
• The plug connector is equipped with a device which allows safe and easy fastening to a panel
• IP68 waterproof rating
• Suitable fo rWire-to-wire connection
• 1/2/3/4 cavity arrangements
• Integrated latch for mating
• Rectangular, thermoplastic housing
• Grommet: Silicone rubber
• Insert Retainer: Thermoplastic
• Receptacle Interfacial Seal: Silicone rubber
• Shell: Thermoplastic
• Wedgelocks: Thermoplastic

Durability: No electrical or mechanical defects after 100 cycles of engagement and disengagement.

Vibration: No unlocking or unmating and exhibits no mechanical or physical damage after sinusoidal vibration levels of 20 G’s at 10 to 2000 Hz in each of the three mutually perpendicular planes. No electrical discontinuities longer than 1 microsecond.

Physical Shock: No unlocking, unmating, or other unsatisfactory result during or after 50 G’s in each of three mutually perpendicular planes. No electrical discontinuities longer than 1 microsecond. MIL-STD 202, Method 213, Condition “C”.

Fluid Resistance: Connectors show no damage when exposed to most fluids used in industrial applications.

Insulation Resistance: 1000 megohms minimum at 25° C.

Moisture Resistance: Properly wired and mated connections will withstand immersion under three feet of water without loss of electronic qualities or leakage.

Dielectric Withstanding Voltage: Current leakage less than 2 milliamps at 1500 VAC.

Thermal Cycle: No cracking, chipping or leaking after 20 test cycles from -55° C to +125° C.

Typical Applications:

• Automotive industry
• Sensors Signal and Power Cables
• Oil pressure senders
• Water temperature monitoring

This Assorted Kit Contains (Total 26pcs of AMP Connector, Plug, Pins)
