Read Article βThis kit includes the heatsink, water block, fan, and other accessories required to build your own peltier-based Water Cooling and Heating system. Use this kit to generate cool and heat the water by circulating it through the water block.
Peltier modules are used to generate a heating and cooling effect using electricity. Semiconductor coolers are a form of solid-state cooling that incorporates semiconductor technologies and electronic assembly techniques. With the wide applications of semiconductor cooling, more and more DIY enthusiasts are interested in it. It's a question of how to make refrigerating capacity to a greater extent heating and cooling applications. This DIY kit could be just the answer that you are looking for.
This Thermoelectric kit is designed and assembled with two water blocks, two Peltier modules, three fans, and heatsinks to achieve the thermal output. Two TEC1-12710 Peltier modules are mounted in between two water blocks in which the insulated block is the cold side circulation and another for the hot side, and additional heatsinks are fixed on the other side of the block to extract heat from the hot side block to air by using the fan which increases the cooling efficiency. Simply connect to a 12V 20A power supply and circulate water through the water block to extract heat or cold. Great for building heat extraction units.
The recommended water circulation pump is 480LPH and with this water flow rate difference temp (ΔT) is 0.2-0.3 degrees per cycle and suitable for a 10 to 40-litre Volume(water).
This assembled kit, contains the Peltier modules, water blocks, heatsink, Condensor, fan, heatsink paste, screws, and connecting wires required to build your own liquid cooling and heating system.
Note:
Features:
Applications:
Specifications:
Package Includes:
1 x 240W 12V Thermoelectric Double Head Peltier Water Cooling Heating DIY KIT
| Operating Voltage: | 12 V |
|---|---|
| Max Current: | 20 A |
| Cooling Medium: | Liquid |
| Heat Extraction: | Air (Heat/FAN) |
| Peltier Module Type: | Thermoelectric Cooler (TEC) |
| Voltage | NA |
