Read Article →The SI5351 square wave signal generator module is your go-to tool for crafting precise and customizable square wave signals effortlessly. This module is designed to generate signals and offer a simple and user-friendly solution for hobbyists and electronics enthusiasts. Widely used for a variety of applications, from radio projects to creating DIY electronic instruments.
The SI5351 square wave signal is an I2C clock generator, as it uses the onboard precision clock to drive multiple PLL's and clock dividers using I2C instructions. By setting up the PLL and dividers, you can create precise and arbitrary frequencies. There are three independent outputs, and each one can have a different frequency. Outputs are 3Vpp, either through a breadboard-friendly header or, for RF work, an optional SMA connector. This handy little chip is mounted onto its breakout board PCB, with a 3.3v LDO regulator so it can be powered from 3- 5vdc. It also features level-shifting circuitry on the I2C lines so you can use this chip safely with 3v or 5v logic.
This SI5351 Clock Signal Generator Module is a versatile and reliable breakout board designed for high-frequency square wave signal generation. Built with high-quality PCB material, this module ensures durability and efficient performance. Its wide logic voltage compatibility (3.3v to 5v) makes it perfect for use with Arduino and other microcontroller-based DIY kits. This module is ideal for signal testing, timing applications, and other electronics projects requiring precise clock signals. With its compact design and straightforward interface, this module is suitable for both beginners and experienced makers. Elevate your projects with the SI5351, a versatile and reliable signal generator that brings simplicity and precision to your electronic experiments.
Downloads & Links:
Features:
Applications:
Package Includes:


Specifications:
Product: I2C Clock Signal Generator
Chip: SI5351
Input Voltage: 3.3v - 5v
Logic Voltage: 3.3v - 5v
Frequency: 8 kHz to 160 MHz
Crystal: 25MHz
Voltage supply pins:
Core VDD: 2.5 or 3.3 V
VDDO output: 1.8, 2.5 or 3.3 V
Pinout


| Signal Output Type | Clock / Square Wave |
|---|---|
| Form Factor / Mounting | Bare Board |
| Control Interface | I2C |
| Display Type | No Display |
