UT372D 2-in-1 contact and non-contact Tachometer UNI-T RPM Measuring Meter

UT372D tachometer is a stable, safe, and reliable measuring device used to measure rotational RPM (Revolutions Per Minute), frequency, surface velocity, and length in the fields of motors, fans, automobiles, papermaking, etc. It has 2 in 1 options as contact and non-contact (optical) RPM measurement modes, which is convenient for users to use on different occasions. Contact Type RPM measurement mode works on the principle of relative motion. The device operates between the shaft of the device and the magnetic field. It works as a generator and produces the voltage as per the velocity of the stick. The device counts the number of rotations that the shaft makes per minute, Whereas the Non-contact RPM measurement is through an optical Sensor. It uses laser light to measure the RPM and is also able to measure any differences in the frequency of the reflected light.

UT372D is also equipped with a mobile app Bluetooth wireless data transmission which makes it convenient for the users to view and export data with charts to PDF, Excel format reports

Note: Batteries not Included

Please read the Instructions Manual  carefully and strictly follow all warnings and precautions

Safety Instructions:

• Please pay attention to the Warning and its symbol. A warning identifies conditions and procedures that are dangerous to users or that can cause damage to the product or the equipment under test.
• Check the meter and accessories before use to avoid any damage or abnormal phenomenon. If the product housing has been damaged and the LCD has no display
• Use the product only as specified. Please do not disassemble the meter or change the internal wiring.
• Replace the batteries when the low battery indicator shows. Remove the batteries if the product is not used for an extended period. When the battery voltage is lower than 3.5V, the low battery indicator is displayed on the screen.
• Do not store or use the product in a high temperature, high humidity, inflammable, explosive, or strong electromagnetic field environment
• Use a soft cloth and detergent to wipe the product housing gently. Do not clean with corrosive solvents or abrasive detergents.
• Do not direct the laser beam into the eyes, which can cause permanent eye damage.

  • Laser radiation:

    • Laser: Class 2
    • beam divergence: ＜1.5 mrad
    • wavelength: 630nm-670nm
    • output power: 1mW

Downloads:

• UT372D -Data Sheet
• UT372D -User Manual
• UT372D-Bluetooth App
