Sipeed Longan Nano RISC-V GD32VF103CBT6 Development Board

Description:

Sipeed Longan Nano is a development board based on the GD32VF103CBT6 MCU with RISC-V 32-bit core by GigaDevice. It is convenient for students, engineers, and geek enthusiasts to tinker with the new-generation RISC-V processors. Longan Nano comes with a 0.96inch 160x80 IPS RGB LCD.

GD32VF103CBT6 is a Bumblebee core, based on Nuclei System Technology. Support RV32IMAC instruction set and ECLIC fast interrupt function. Core power consumption is only 1/3 of that of traditional Cortex-M3.

Longan Nano development board has a double-row pin layout design with a needle spacing of 700 mil, which can be inserted directly into a breadboard. Also, it has an onboard 8M passive crystal oscillator, 32.768 kHz RTC low-speed crystal oscillator, Mini TF slot, and uses Type-C USB interface.

Longan Nano supports multiple download methods: USB DFU download, UART ISP download, JTAG download. In the USB DFU download mode, you only need a USB Type-C cable to download the program to the development board. At the same time, Longan Nano supports the standard JTAG interface, which can be debugged online using the in-store RISC-V debugger or any JTAG-enabled debugger such as J-Link.

Specifications

• CPU: GD32VF103CBT6 based on RISC-V 32-bit core
• Kernel power consumption: Only 1/3 of the traditional Cortex-M3
• Chip built-in: 128KB Flash, 32KB SRAM
• Crystal: 8MHz Passive High-Speed Crystal +32.768KHz Low-Speed RTC Crystal
• Debug interface: 2x4 pin leads to JTAG debug interface
• Display expansion: 8pin 0.5mm FPC Block Expansion 160x80 RGB IPS LCD (SPI Interface)

Package Includes:

1 x Sipeed Longan Nano RISC-V GD32VF103CBT6 Development Board
