TTGO ESP32 WiFi and Bluetooth Development Board with 1.14″ LCD Display

₹1,799.00 ₹ 1524.58 + 274.42 GST
In stock
SKU
PRO1786

Description:

This is TTGO board is based on the ESP32-D0WDQ6 Wifi Module comes with a built-in 1.14inch display and also it has an onboard battery connector and battery management system. The board has an onboard USB Type – C connector which can be used to provide power and to upload code to the ESP32.

Specifications


Chipset ESPRESSIF-ESP32 LX6 32-bit single / dual-core Xtensa® 240MHz microprocessor
FLASH 4MB / 16MB QSPI Flash
SRAM 520 kb SRAM
Button Reset
USB to TTL CP2104
Modular interface UART, SPI, SDIO, I2C, LED PWM, TV PWM, I2S, IRGPIO, ADC, capacitor touch sensor, DACLNA pre-amplifier
Display IPS ST7789V 1.14 Inch
Working voltage 2.7V-4.2V
Working current About 67MA
Sleep current About 350uA
Working temperature range -40 ℃ ~ + 85 ℃
Height and weight 51.52 * 25.04 * 8.54mm (7.81g)
Supply Voltage USB 5V / 1A
Charging current 500mA
Drums 3.7V lithium battery
JST connector 2Pin 1.25mm
USB Type-c



Wireless


Standard FCC / CE-RED / IC / TELEC / KCC / SRRC / NCC (esp32 chip)
Protocol 802.11 b / g / n (802.11n, speed up to150Mbps) A-MPDU and A-MSDU polymerization, support 0.4μS Protection Interval
Frequency range 2.4GHz ~ 2.5GHz (2400M ~ 2483.5M)
Transmission power 22dBm
Communication distance 300m



Bluetooth


Protocol Complies with Bluetooth v4.2BR / EDR and BLE standard
Radiofrequency With sensitivity-97dBm receiver NZIF class-1, class-2 and class-3 AFH transmitter
Audio frequency CVSD & SBC audio frequency



Software Specifications


Wi-Fi mode Station / SoftAP / SoftAP + Station / P2P
Safety mechanism WPA / WPA2 / WPA2-Enterprise / WPS
Encryption Type AES / RSA / ECC / SHA
Firmware upgrade UART / OTA download (via network/host to download and write firmware)
Software development Support cloud server / SDK development for user firmware development
Network protocol IPv4, IPv6, SSL, TCP / UDP / HTTP / FTP / MQTT
User configuration AT + instruction set, cloud server, android / iOSapp



Package Includes:

1 x TTGO ESP32 WiFi and Bluetooth Development Board with 1.14″ LCD Display
