MB102 830 Points Solderless Prototype Breadboard - 2.54mm Pitch, Power Rails βΉ100.00 Guide pins are important pins that can be fixed to the Bed of Nails or test Fixtures (Pogo pins) to serve as guides during the placement of PCB for testing. It allows PCB to align in the proper position and orientation on a Bed of Nails for mating connection of high-density pogo pins and test pads for transfer of digital information therebetween. These are great for programming and Test Jig applications.
Guide pins are mainly used to prevent mating Bed of Nails(Pogo pins) and Testing PCB being damaged due to misalignment when Bed of Nails is connected to Testing PCB during the connectivity process and also ensure that each pogo pin or connector is aligned properly during the insertion cycle
These guide pins come with a 1.6mm Cone Head solid Pin and M4 thread for mounting. They are mainly mounted to the bed of nails of the test Jig. It has a maximum guide pin length of 25mm.
Features:
Applications:
Specifications:
Installation:
Package Includes: 1 x 1.6mm Cone Head solid Guide Pin for PCB Positioning alignment with M4 thread
Note: Variations in panel hole size, thickness, material, and installation methods will affect the loads. Values may not be consistent with loading in an assembly. Strongly recommended for testing in the application
