USB 3.0 to USB 3.0 Type-A Pass through Panel Mount Connector - Female Coupler

Specifications

• Interface Type: USB 3.0 Type-A Female (Front) to USB 3.0 Type-A Female (Back)

• Mounting Style: Flange / Panel Mount (D-Type)

• Data Rate: Up to 5Gbps

• Contact Material: High-conductivity copper alloy

• Housing: High-impact black thermoplastic/metal composite

• Dimensions: Standard industrial D-type footprint

Key Applications and Projects

• Custom Enclosures: Adding a professional USB port to 3D-printed or metal project boxes for easy external access.

• Server and Rack Integration: Centralizing connectivity on rack-mount panels for cleaner cable management.

• Industrial Workstations: Providing a ruggedized, replaceable interface point for field equipment to protect internal motherboards from wear.

Unlock New Capabilities (Project Evolution)

• Efficiency Upgrade: Transition from dangling cables to a clean bulkhead interface, reducing cable strain and potential connection failures in permanent installations.

• Speed Upgrade: Replace legacy USB 2.0 ports with this USB 3.0 coupler to achieve 10x faster data transfer for external storage devices.

Package Includes:

• 1 x USB 3.0 Type-A Female-to-Female Pass Through Panel Mount Connector

FREQUENTLY ASKED QUESTIONS (FAQ)

• Does this require any soldering? No, it is a female-to-female coupler; you simply plug standard USB cables into both sides.

• What size are the mounting holes? The holes are standard D-type, typically requiring M3 screws for installation.

• Is it compatible with USB 2.0? Yes, it is fully backwards compatible with USB 2.0 and 1.1 cables and devices.

• Can I use this for charging? Yes, it supports the standard power transmission required by USB 3.0 devices.

• What is the maximum data speed? It supports SuperSpeed data transfer up to 5Gbps.

• Does it include mounting screws? Usually, screws are not included as the required length depends on your specific panel thickness.

• What is the color code for the port? The connector features a blue insert, identifying it as USB 3.0.

• Is the flange material metal or plastic? It is constructed from a high-impact industrial thermoplastic designed for structural durability.

• Can I mount this on a 3D-printed box? Yes, it is ideal for 3D-printed enclosures; just ensure your hole spacing matches the D-type flange.

• What is a "Pass-through" connector? It means the electrical signal goes directly through without gender changes—it acts as a bulkhead extension.

• Does it support USB OTG (On-The-Go)? Yes, provided the cables and devices connected to it support OTG functionality.

• Can I use this in a patch panel? Absolutely; it is designed to fit standard XLR-sized D-series cutouts commonly found in audio and data patch panels.

• Is it shielded? Yes, the internal structure is designed to maintain signal integrity and reduce EMI, compliant with USB 3.0 standards.

• How deep is the connector? The total depth is designed to allow standard USB male connectors to sit flush on the rear side of the panel.

• What is the mounting hole pitch? It follows the industry-standard 19mm x 24mm mounting hole spacing for D-type connectors.

• Can I use this for a Raspberry Pi project? Yes, it is a popular choice for bringing the internal Pi USB ports to the outside of a case.

• Is the connector reversible? No, the flange has a specific "up" orientation, and the USB Type-A ports are non-reversible.

• Does it work with USB 3.1 or 3.2? It will work at USB 3.0 speeds (5Gbps), which is the physical limit of this specific coupler.

• What is the temperature rating? Most industrial couplers are rated for -20°C to +60°C, suitable for server rooms and factory floors.

• Is there a dust cap available? While not included, standard D-type rubber dust caps can be fitted to the front flange.
