TMC2209 Stepper Motor Driver Controller Module with UART

₹849.00 ₹ 719.49 + 129.51 GST
In stock
SKU
PRO3307

1-7 Days Express Delivery in India Available

  • Latest V2.0 version of the Popular TMC2209 StepStick Module
  • Traditional STEP/DIR & UART Control
  • Advanced UART Control offers current setting, microstep setting, stepper control etc.
  • High performance upgrade resulting in smooth, noise free, efficient operation with max toque and low heating

Advanced Stepper Motor Driver with STEP/DIR and UART Control. Offers considerable improvement in performance compared to previous generation stepper motor drivers. TMC2209 SilentStepStick is a step/direction driver for two-phase bipolar stepper motors having a current of up to 2.8A peak to peak and 2A RMS. It can drive a 2-phase bipolar stepper motor from 1 to 1/256 steps mode. On top of that, TMC2209 offers a simple UART interface to tune and control with the help of any microcontroller having a UART port.

These steps can be configured into 9 different micro-step resolution settings. The device is low-power, cost-effective and reliable

This module can drive one stepper motor. Use this board to control your stepper motor from your microcontroller, Arduino, RaspberryPi, etc. It uses the hugely popular Texas Instruments DRV8825 IC. The stepper motor can be controlled through just 2 pins - one for direction and the other for speed and step control. This makes it easy to control the speed and position of the motor from a microcontroller, Arduino, Raspberry Pi, etc.

It offers numerous features like features adjustable current limiting, over-current and over-temperature protection, and six different microstep resolutions (down to 1/32-step). It can drive stepper motors with an input voltage of 8V to 45V and can deliver up to approximately 1.5 A per phase without a heat sink or forced air flow (it is rated for 2.2 A per coil with sufficient additional cooling).

Features

  • Maximum Operating Voltage: 4.5V to 28V DC
  • Input Signal Logic Volatage: 3.3V to 5V DC
  • Maximum Peak Current: 2.8A per phase
  • Maximum Continuos Current: 2A per phase (use with Heatsink and Fan only)
  • Offers low noise & smooth high precision movement
  • Popularly used for controller Stepper motors for 3D Printers
  • Simple step and direction control interface
  • Microstepper with Chopper Driver
  • Compatible with 3V3 and 5V microcontrollers
  • Adjustable current control lets you set the maximum current output with a potentiometer, which lets you use voltages above your stepper motor’s rated voltage to achieve higher step rates
  • Intelligent chopping control that automatically selects the correct current decay mode (fast decay or slow decay)
  • Over-temperature thermal shutdown, under-voltage lockout, and crossover-current protection
  • Special Features: MicroPlyer, StealthChop2, SpreadCycle, StallGuard and CoolStep
  • Suitable Applications: 3DPrinters, Desktop Printers, CCTV, HVAC, Home Automation, Battery Operated Devices
  •

MC2209 Special Features

  • StealthChop2™ A highly precise and noiseless code for silent motion and inaudible standstill of the motor. It permits acceleration and deceleration faster than the StealthChop™ and escalates it to low standstill currents.
  • SpreadCycle™ The code acquires the highest dynamic motion through cycle-by-cycle current control.
  • MicroPlyer™ Microstep interpolator is for obtaining full 256 micro-step smoothness with lower resolution and maximum efficiency.
  • StallGuard4™ This sensorless feature informs about motor overload when it has reached its mechanical stop.
  • CoolStep™ For better efficiency and less heating up of the 2 phase stepper and drive StallGuard measurement is to be used.

TMC2209 Applications -

This stepper motor driver is specially designed to be used in motion control applications for -

  • 3D printers, CNC Machines, Laser Cutting and Plotters
  • Home & Industrial Automation Machines
  • Robotics Drives, Arms, & Linear Actuators
  • ATM Machines
  • Security purposes
  • Textile industry
  • Printers & Scanners
