DM556 Digital Stepper Motor Driver 5.6A DC 20V-50V NEMA17 NEMA23 NEMA34

₹2,299.00 Rs. 1948.31 + 350.7 GST
Professional Plug & Play Stepper Motor Driver to control stepper from MCU and PLCs. Implements high performance driving, current chopping algorithm to provide smooth operation and long life.
In stock. 1-7 Day Delivery in India.
SKU
PRO1391

Description:

This is a plug & play stepper motor driver for NEMA17, NEMA23, NEMA32 and other compatible stepper motors. Easy & Simple connection allows users to get their stepper running in the shortest time.

The DM556 is a versatile fully digital stepping drive based on a DSP with an advanced control algorithm. The DM556 is the next generation of digital stepping motor controls. It brings a unique level of system smoothness, providing optimum torque, and nulls mid-range instability. Motor self-test and parameter auto-setup technology offer optimum responses with different motors and easy-to-use.

The advantage of using the DM556 Stepper Motor Driver is to control the direction, speed and position of the stepper motor. These kinds of drivers can be used for a wide range of stepper motors. Using these kinds of drivers one can eliminate the external code and connections required to drive a stepper motor. In this driver, a new feature has been added where we can set the current Mode. SW4 is used for this purpose. OFF meaning that the standstill current is set to be half of the selected dynamic current, and ON meaning that the standstill current is set to be the same as the selected dynamic current.

The driven motors can run with much smaller noise, lower heating, and smoother movement thanmost of the drives in the markets. Its unique features make the DM556 an ideal solution for applications that require low-speed smoothness.


Specifications:

  • Easy & Simple connection to drive stepper motors. Control the speed and direction of motors using just 2 digital IO pins
  • Suitable for use with Microcontrollers and PLCs
  • Can also be used along with manual circuits requiring no external microcontroller or PLC. You will have to generate pulses to trigger each step
  • Microstepping lets you control the stepper with max resolution
  • Current limiting lets you use the stepper at higher voltages without damaging the internal coils
  • Anti-Resonance provides optimum torque and nulls mid-range
    instability
  • Motor self-test and parameter auto-setup technology offer optimum
    responses with different motors
  • Multi-Stepping allows a low-resolution step input which inturn produces a higher micro-step output for smooth system performance
  • Microstep resolutions programmable, from full-step to 102,400
    steps/rev
  • Supply voltage up to +50 VDC
  • Output current programmable, from 0.5A to 5.6A via DIP switches
  • Pulse input frequency up to 200 kHz
  • All Digital Inputs are TTL compatible and optically isolated input
  • Automatic idle-current reduction
  • Suitable for 2-phase and 4-phase motors
  • Support PUL/DIR and CW/CCW modes
  • Over-voltage, over-current, phase-error protections

Applications:

  • Suitable for controlling compatible stepper motors from microcontrollers and PLCs
  • 3D Printers
  • CNC Spindles and Drives
  • Laser cutters,
  • Laser markers,
  • High precision X-Y tables,
  • Labelling machines, etc.

Package includes:

1 x DM556 Stepper Motor Driver Controller

Write Your Own Review
You're reviewing:DM556 Digital Stepper Motor Driver 5.6A DC 20V-50V NEMA17 NEMA23 NEMA34
Your Rating

Probots DM556 Stepper Motor Connections with PLC / External Controller



Probots DM556 Stepper Motor Connections with Arduino
