Timing Delay Relay Programmable Module 220V AC DC One Shot Cyclic

₹799.00 ₹ 677.12 + 121.88 GST
In stock
SKU
PRO3058

1-7 Days Express Delivery in India Available

This is an industrial grade programable delay timer. Timer can be triggered by an input signal and offers options like setting on time, off time, looping, single shot, etc

Specifications:

Model: Time Delay Relay
Timing range: 0-999s,0-999m,0-999h
Power supply voltage: AC 110V-220V
LED Display: Red + Blue Dual Display
Size: 79 x 26 x 43mm
Hole size: 72 x 40mm

Instructions:

1.After setting the data, you must wait 6 seconds,6s post modules automatically save memory set data.
2.Press SET key once to enter the time setting mode,the red LED flashes, press the key to increase or decrease the setting time T1.
3.After setting time T1,short press the SET key again, the green LED flashes,and the time is set by pressing the key Time T2, T2 time setting is completed,press SET key again, the system will automatically save the memory setting time or wait for 6s, 6s module will automatically save the data memory.
4.Long press SET,enter parameter setting mode.There are two sets of parameters for the user to select P0, P1.Short press SET in the current mode to switch between P0 and P1.
5.In P0 parameter can be set by pressing the key to adjust their own timing mode.In the P1 parameter can be set by adding and subtracting keys work mode.
P0--0:T1 Timing mode is second.
P0-1: T1 timing mode is minutes.
P0--2:T1 Timing Time mode is hour.
P1--0:Delay T1 time,relay pull(T1 timer)
P1--1:Relay release after T1 time delay (T1 timer)
P1--2:Delay T1 time,relay pull(T1 timer),and then relay release after T2 time delay(T2 timing),then it is finished.
P1--3:Relay release after T1 time delay(T1 timer),then delay T2 time,relay pull(T2 timing),then it is finished.
P1--4:Delay T1 time,relay pull(T1 timer),and then relay release after T2 time delay(T2 timer),cycling.
P1--5: Relay release after T1 time delay(T1 timer),then delay T2 time,relay pull(T2 timer),cycling.

Package Included:

1 x Time Delay Relay Module

This is an industrial grade programmable delay timer module. Timer can be triggered by an input signal and offers advanced options like setting on time, off time, looping, single shot, etc

The timer offers multiple operating modes(P0 to P1) and users can select them as required. Complex timer functions with different on/off times, looping/restarting can be programmed.

All the programming happens onboard using the Display and Keypad.

Stuiable for industrial environments the timer comes with panel mounting.

The timer includes an onboard relay to directly control DC and AC Loads (max 5A). For higher loads, it is safe to connect a high power relay/contactor in between.

Video showing how to use the timer in your application

Note: We have the same timer in different operating voltages - 12V DC, 24V and 220V AC. Checkout our website - www.probots.co.in and purchase the one required for your application

Specifications:

  • Model: Probots Time Delay Relay Module
  • The timer automatically saves data after 6 seconds of inactivity
  • Timing range: 0-999s, 0-999m or 0-999h
  • Power supply voltage: 220V AC
  • LED Display: Red + Blue Dual Display
  • Size: 79 x 26 x 43mm
  • Hole size: 72 x 40mm

Instructions:

  • After setting the data, you must wait 6 seconds, post 6s modules automatically save memory
  • Press SET key once to enter the time setting mode, the red LED flashes. Press the key to increase or decrease the setting time T1.
  • After setting time T1, short press the SET key again, the green LED flashes. The time is can now be set by pressing the key Time T2. Once T2 time setting is completed, press SET key again, the system will then automatically save the memory setting time
  • Long press SET to enter parameter setting mode. There are two sets of parameters for the user to select P0 & P1. Short press SET in the current mode to switch between P0 and P1.
  • In P0 parameter can be set by pressing the key to adjust their own timing mode. In the P1 parameter can be set by adding and subtracting keys work mode.
  • P0--0: T1 Timing mode uses seconds.
  • P0-1: T1 timing mode uses minutes.
  • P0--2:T1 Timing Time mode uses hour.
  • P1--0: Delay T1 time, relay on for T1 time
  • P1--1: Relay off after T1 time delay (T1 timer)
  • P1--2: Delay T1 time, relay on(T1 timer), and then relay off after T2 time delay(T2 timing), timer is complete
  • P1--3: Relay off after T1 time delay(T1 timer), then delay T2 time, relay off(T2 timing), timer is complete
  • P1--4: Delay T1 time,relay on(T1 timer),and then relay off after T2 time delay(T2 timer), keeps cycling
  • P1--5: Relay off after T1 time delay(T1 timer),then delay T2 time,relay on(T2 timer),cycling

Applications:

  • To control external loads like AC Mains Lights, Fans, Motors, etc from low voltage signals
  • To drive loads for longer time compared input signals
  • Home Automation, Access Control, Door lock/unlock, etc

Package Included:

  • 1 x Time Delay Relay Module
