Official Raspberry Pi 5 Case Red/White with Integrated Cooling Fan

Specifications

• Compatibility: Raspberry Pi 5 (All RAM variants)

• Material: High-quality, heat-resistant ABS plastic

• Cooling: Integrated variable-speed PWM cooling fan (pre-installed)

• Assembly: Snap-together, tool-less design (no screws required)

• Access Ports: Full access to GPIO, USB, Ethernet, Power, Micro HDMI, and microSD slot

• Special Features: Removable top lid for GPIO access and HAT compatibility

• Dimensions: 98.5 mm W x 70.3 mm D x 33 mm H

• Colour: Official Raspberry Pi Red and White

Applications

• Desktop Replacement: Keeps the Pi 5 cool during long web-browsing sessions or office tasks.

• Media Centre (Kodi/LibreELEC): Silent fan operation ensures a quiet entertainment experience.

• Edge Computing: Robust protection for boards deployed in light industrial environments.

• Development Workstation: Removable lid allows for easy sensor wiring and HAT mounting.

Project Evolution

• Past Projects (Prerequisites): If you've used the Pi 4, you know it gets hot. The Pi 5 runs even hotter.

• Feature Upgrade: This case unlocks Consistent Peak Performance. By utilising the dedicated fan header on the Pi 5, the integrated fan adjusts its speed based on real-time temperature data, ensuring you don't lose speed during 4K video playback or AI compilation.

• Effort/Requirements: Beginner. No tools required. Just snap the board into the base and connect the fan cable.

Virtual Technician & Wiring

• ⚠️ Safety Warning: Ensure the Raspberry Pi 5 is powered off before connecting the fan cable to the dedicated 4-pin fan header on the board.

• Fan Connection: Connect the pre-installed fan to the header located between the GPIO pins and the USB ports.

• SD Card: Insert the microSD card after snapping the board into the case to prevent damaging the card or slot.

Package includes:

• 1 x Official Raspberry Pi 5 Case Red/White with Integrated Cooling Fan

Frequently Asked Questions (FAQ)

• Does this case include the Raspberry Pi 5 board?
  No, this is the enclosure and fan only.
• Is it compatible with Raspberry Pi 4?
  No, the port layout for the Pi 5 is significantly different.
• Does the fan run all the time?
  No, it is a PWM fan that adjusts speed based on the CPU temperature.
• Do I need tools to assemble it?
  No, it features a completely tool-less, snap-together design.
• Can I use HATs with this case?
  Yes, the top lid is removable to accommodate most Raspberry Pi HATs.
• Are there non-slip feet included?
  Yes, the case comes with adhesive rubber feet for stability.
• Does the case block the Wi-Fi signal?
  No, the ABS plastic is transparent to RF signals.
• Where do I plug in the fan?
  There is a dedicated 4-pin fan header on the Raspberry Pi 5 board.
• Can I access the GPIO pins?
  Yes, by removing the white top cover.
• Is there room for the Official Active Cooler?
  This case comes with its own fan; the Active Cooler is usually used in place of this case or in "naked" setups.
• Does it have access to the power button?
  Yes, the case includes a plastic actuator for the Pi 5 power button.
• Are the status LEDs visible?
  Yes, the case features light pipes to show the power and activity LEDs.
• Can I mount it on a wall?
  There are no dedicated VESA mounts, but it can be easily modified or used with double-sided mounting tape.
• What is the noise level of the fan?
  The fan is extremely quiet under normal loads and only becomes audible at high RPMs.
• Does it support the PCIe FPC cable?
  Yes, there is a slot for the FPC cable to pass through to an NVMe shield.
• Is the plastic fire-retardant?
  It is made of high-quality ABS with standard fire-rating for consumer electronics.
• Can I use this with a POE+ HAT?
  It may require removing the internal fan or lid depending on the HAT height.
• Is the fan replaceable?
  Yes, the fan is a standard part, though the official one is optimized for this case.
• Does it come in other colors?
  Currently, we stock the signature Red/White variant.
• Will it fit the Pi 5 2GB, 4GB, and 8GB models?
  Yes, it fits all RAM variants of the Raspberry Pi 5.
