Oscilloscope Probe Kit HP-3060 60Mhz

₹999.00 ₹ 846.61 + 152.39 GST
In stock

Poke and prod your electronics with a new 'scope probe. This is a classic probe, good quality and has a nice strong spring-clip and grounding clip. Good for up to 60MHz signals, with a standard oscilloscope BNC connector. Comes as shown, the ring colour on the body of the probe/connector may vary.

The HP-3060 is a passive high impedance oscilloscope probe designed and calibrated to use the instruments having an input impedance of 1 M ohm shunted by 20pf. However it may be compensated to use the instruments having an input capacitance of 10 to 30pf.

The probe incorporated a two position slide switch in the head which selects attenuation of x1, x10 position.

Specification :

Attenuation ratio 10:1
Bandwidth : DC to 60 Mhz
Rise Time : 5.8nS
Input Resistance : Approx. 18pF
Compensation range : 10 to 30pF
Max. Input Voltage : 600V CAT 1, 300V CAT 2(DC+ Peak AC) derating with frequency
Operating temperature : 0 - 50 Degree Celsius
Humidity : 85% RH or less (at 35 C)
Cable Length : 1.2 Meter
