OKDO ROCK 5 Model B 8gb Ram Single Board Computer 8K

₹27,999.00 ₹ 23727.97 + 4271.03 GST
In stock

1-7 Days Express Delivery in India Available

OKDO ROCK 5 Model B (ROCK 5B) is a Single Board Computer (SBC) in a compact form factor packed with a wide range of class‑leading functionality, features, and expansion options.

The OKDO ROCK 5B is an ideal choice for makers, IoT enthusiasts, hobbyists, gamers, PC users, and everyone who needs an extremely highly specified platform with outstanding performance and reliability. The ROCK 5B  is built on a high‑performance mobile chipset that is designed to operate for extended durations on batteries with efficiency at its core. The ROCK 5B  has been designed to operate between 0°C to 50°C. This temperature range was defined based on typical usage where the efficient use of Arm big.

If the OKDO ROCK 5B  is intended to be used continuously in high-performance applications, it may be necessary to use external cooling methods (for example, heat sink, fan, etc.) which will allow the SoC to continue running at maximum clock speed indefinitely below its predefined 80°C peak temperature limiter. This temperature range was defined based on typical usage where the efficient use of Arm big.



  •  Rockchip RK3588 SoC
  • Quad Cortex®‑A76 @ 2.2/2.4GHz and a quad Cortex®‑A55 @ 1.8GHz based on Arm® DynamIQ™configuration
  • Arm Mali™ G610MC4 GPU supporting:
    – OpenGL® ES1.1, ES2.0, and ES3.2
    – OpenCL® 1.1, 1.2 and 2.2
    – Vulkan® 1.1 and 1.2
    – Embedded high-performance 2D image acceleration module
  • NPU supporting INT4/INT8/INT16/FP16/BF16 and TF32 acceleration and computing power is upto 6TOPs
  • 64bits LPDDR4x RAM: 8GB
  • Able to provide 4 display outputs via two HDMI, one DP (type C), and one MIPI DSI
  • H.265/H.264/AV1/AVS2 multi video decoder up to [email protected]
  • H.264/H.265 multi-video decoder up to [email protected]


  • 1x Full function USB Type‑C™ port supporting:
    – PD Version 2.0
    – DP display up to 4Kp60
    – USB 3.0
  • 1x Micro SD Card
  • 2x Standard HDMI output ports, one supporting displays up to 8Kp60 resolution, one supporting up to 4Kp60
  • 1x Micro HDMI input port, supporting up to 4Kp60 display input
  • 2x USB2 Type A HOST ports
  • 1x USB3 Type A HOST port, 1x USB3 Type A OTG/HOST port
  • 1x 2.5 Gigabit Ethernet port (supports PoE with add‑on PoE HAT)
  • 1x M.2 M Key with PCIe 3.0 four‑lane support
  • 1x M.2 E Key with PCIe 2.1 one‑lane, SATA, SDIO, PCM, UART support
  • 1x eMMC module connector for eMMC 5.1 support. The eMMC module shall be larger than 8GB.
  • 1x Camera port (1x four‑lane MIPI CSI or 2x two‑lane MIPI CSI)
  • 1x Display port (four‑lane MIPI DSI)
  • Miscellaneous
    – 1x RTC battery connector
    – 1x PWM fan connector
    – 1x Power button
    – 1x Recovery button
    – 1x RGB power/status/user LED
    – 2x heatsink mounting holes
  • 40 pin 0.1” (2.54mm) header supporting a wide range of interface options:
    – 2 x UART
    – 2 x SPI bus
    – 2 x I2C bus
    – 1 x PCM/I2S
    – 1 x SPDIF
    – 1 x PWM
    – 1 x ADC
    – 6 x GPIO
    – 2 x 5V DC power in/out
    – 2 x 3.3V power out


  • ArmV8 Instruction Set
  • Debian/Ubuntu Linux support
  • Android 12 support
  • OpenFyde OS(Chromium OS fork) support
  • RKNPU2 NPU software stack
  • Hardware access/control library for Linux/Android

Package Includes:

1 x OKDO ROCK 5 Model B 8gb Ram Single Board Computer 8K


OKDO ROCK 5 Model B 8gb Ram Single Board Computer 8K Overview
More Information
Technical Details


  • Make: OKDO

  • Type of kit: Single-board computer

  • RAM memory capacity:8GB

  • Processor: ARM Quad Core Cortex®-A55, ARM Quad-Core Cortex®-A76

  • Dimensions:100.15x74.25mm

  • Kind of memory: LPDDR4

  • Operating system: none

  • Kind of architecture: ARM, Cortex A55, Cortex A76

  • Operating system support: Android, Linux Debian, Ubuntu

  • Kit contents: Single-board computer

  • Video coding: H.264, H.265, OpenCL 1.1/1.2/2.2, OpenGL ES 1.1/2.0/3.0, Vulkan® 1.1/1.2

  • Communications protocol: Ethernet

  • Supply voltage: 5-20V DC

  • Interface: ADC, Audio, Ethernet, GPIO, HDMI, I2C x2, I2S,microSD, MIPI-CSI, MIPI-DSI, PWM, SPDIF, SPI x2, UARTx2, USB

  • Kind of connector: eMMC, Jack 3,5mm, HDMI x2, M.2 (M key), MIPI-CSI, MIPI DSI, pin strips, RJ45, RTC battery, USB 2.0x2, USB 3.0 x2, USB C socket

  • Gross weight:123.5 g



Write Your Own Review
Only registered users can write reviews. Please Sign in or create an account

How to Order?

Probots sells every Electronics Part for your next Project. You can order 10,000+ Electronic Parts Online - Arduino, Raspberry Pi, NodeMCU Development Boards, Sensors, Motors, Motor Drivers, SMPS, Plastic Enclosures etc in India directly on probots.co.in

  • Placing an order online our website probots.co.in for quick and fast delivery
  • You can contact us by whatsapp or mail for bulk enquiries, technical queries or order related enquiries before placing the order.
  • If you require a Quotation or PI for your company, send us a mail and we will help you with it.

Delivery Time?

We delivery electronics components and parts throughout India using standard couriers like Bluedart, Delhivery & India Post.

  • Dispatch Time: 1 Working Day for most orders
  • Guranteed Delivery Time: 1-7 days within India under Express Shipping

How to buy Electronics Components in Bangalore?

  • We offer store pickups for walkin customers in Bangalore. This is the fastest way to get electronic components in Bangalore.
  • Customers can visit our store to buy parts directly
  • Alternatively, you can place orders online and select Select Pickup as the delivery option and have your order picked up by Dunzo, Porter, etc. Please contact us for confirmation before arranging a pickup.

Need Help?

For order related queries contact -

Probots sells every Electronics Part for your next Project. You can order 10,000+ Electronic Parts Online - Arduino, Raspberry Pi, NodeMCU Development Boards, Sensors, Motors, Motor Drivers, SMPS, Plastic Enclosures etc in India directly on probots.co.in

We offer specialized services for Bulk, Wholesale & B2B Customers like discounted prices, additional shipping options, customised products, etc . Customer with large quantity & regular orders qualify for the specialised discounted rates.

We also offer dedicated sales team to assist you with the order process by providing sales quotations, PI, technical support for choosing products, etc.

Note: Business Orders are processed manually and usually take 1-3 days  to process compared to placing the order directly on our website. Please plan your purchases accordingly.

Need Help?
For bulk enquiries contact us by  -

Related Products

Similar Products in this Category
Raspberry Pi RP2040 with 0.42  OLED Development Board RP2040-0.42LCD
Raspberry Pi RP2040 with 0.42 OLED Development Board RP2040-0.42LCD
₹1,999.00 ₹ 1694.07 + 304.93 GST
Raspberry Pi Pico W
Raspberry Pi Pico W
₹899.00 ₹ 761.86 + 137.13 GST
Raspberry Pi 3 Camera Module Board 5MP 1080p
