Micro FPV Camera with 5.8Ghz AV Transmitter 25mW 40 Ch

This is a micro FPV Camera that is perfect ultra micro drones and planes. It combines an FPV camera, transmitter, and antenna into a single unit. It’s compatible with Fat Shark and other popular FPV headsets equipped with analog 5.8GHz receivers.

Installation is easy and can be done in seconds. No soldering or special skills are required. You simply attach it to your model and plug in a 1S battery (sold separately). A Y-harness connector is included if you want to eliminate the weight of a separate battery and power the camera with the same 1S flight battery that powers the aircraft.

It is plug-and-play and requires no external FPV transmitter. This reduces weight and connections. Also makes it easy and fast to get your FPV Drone up and running.

Specifications:

• Power Supply: 2.5V to 5V
• Model Number: FX797T
• 5.8 GHz Tx
• Super Small and Lightweight
• 5 bands 40 channel with race band
• Output power: 25mW
• Input power: 2.5¨C5V
• Current Consumption: 230mA
• AV Output: VGA 640x480 PAL/1VP-P
• Camera resolution: 600TVL
• Field of view: 120 degree viewing angle
• Antenna dimensions: 20mm X 25mm diameter
• Antenna: 3 lobe right hand circular polarized
• Video output: NTSC
• Frequency: 5.8GHz 5 bands 40 channels, with Raceband: 5658-5917MHz
• Push button operation, long press for band, short press for channel
• 2 row LED indicators, 5 LED for band, 8 LED for channel
• Size: 17x17.5x12.5mm
• Weight: 3.4g

Package Includes:

1 x FPV Camera with 5.8Ghz Transmitter
