3S 20A BMS Battery Management System Lithium Charger 18650 Protection Module

₹159.00 Rs. 134.75 + 24.26 GST
In stock. 1-7 Day Delivery in India.
SKU
PRO2407

Description:

Lithium-Ion Battery Packs need to be Balanced Charged and protected from Over Charge and Over-Discharge. This ensures the safety of the circuit and gives optimum battery life preserving the original capacity through use. You can use this Battery Management System(BMS) to ensure these conditions. It also offers short circuit protection.

If you are using a 3S Lithium Battery in your project, you can also use this BMS Module to protect it from short circuits in the circuit. In the event of a short circuit, the BMS will cut power to the battery and restart.

 This module provides overcharging, over-discharging, short circuit, and also overcurrent draw protection to the Battery Pack. It also charges the battery in a balanced manner.

For any protection condition, the 3S 20A Lithium-Ion BMS Module recovers automatically after some time after the protection trigger condition is not present.

NOTE: Before, attaching the battery pack or making a battery pack, ensure that all the batteries in the battery pack are having the same voltage level, if any of the battery is having a different voltage then give it a cycle of charge/discharge and make all batteries at the same voltage level than only attach it with Battery Management System.

Features :

  • 3S  20A 18650 lithium battery protection board (comes with recovery function-AUTO Recovery).
  • Application: Nominal voltage of 3.6V, 3.7V lithium battery (including 18650.26650, a polymer lithium battery).
  • Continuous discharge current (upper limit): 20A (if the cooling environment is not good, please reduce the load current use).
  • Continuous charge current (upper limit): 20A.
  • Suitable for the drills with starting current below 80A, power 135W below.
  • Battery: 3 Cell
  • Overcharge detection voltage (V): 4.25±0.025
  • Discharge voltage range (V):2.3 ~ 3.0±0.05v
  • Continuous charge current (A):20

Package Includes:

1 x Lithium Battery Charger BMS 18650 Protection Module Circuit (3S, 20A)
