Door Lock Sensor Magnet Proximity Reed Switch with NO Output 2 terminal

₹235.00 Rs. 199.15 + 35.85 GST
In stock. 1-7 Day Delivery in India.

This is a simple to use magnetic door lock sensor. Consists of a Magnet and a Magnetic Sensor. The sensor has a simple switch within it which gets activated in the presence of a magnet. To use the sensor as a door/window lock sensor, mount the magnet on the door/window and the magnet sensor on the door/window frame. When they are separated, the magnet sensor detects that the door/window is opened. This sensor can be used with other commonly available magnets also.

This sensor is perfect for use in general magnet sensing applications, door lock sensors, drawer lock sensors, Window Lock Sensors, encoders, etc. It comes with mounting tabs and holes for mounting it to a flat surface.

Note: There is no wire attached to the switch. It's just the switch without wire.

Features :

Switch pattern: NO Normally Open
Max Voltage: 100V DC, 0.3A
Max Rated power: 10W
Sensing Distance: 10-15mm Approx. if you need a longer range please use an external stronger magnet.
Mounting method: SMD (by screws or double-sided tapes)

Color: White
Dimension: 64 x 20 x 13 mm
Quantity: 1 Set With 4 screws
