LockIT 12V Electromagnetic Door Bolt Lock Heavy Duty

₹1,999.00 ₹ 1694.07 + 304.93 GST
Out of stock
SKU
PRO2885

This electric lock is popularly used in Access Control Systems. This bolt lock can be activated electronically. This is a heavy-duty lock made for durability and long use.

The lock is disengaged(unlocked) when powered. The lock activates the bolt only when it detects the metal plate in the door frame. This makes the lock easy to use and safe. Just keep the lock powered and it will lock the door when it senses that the door has been closed. You will only have to cut power to unlock it.

It consists of an electric door lock, a steel plate, and mounting accessories. When powered, the bolt lock extends to lock the door. When power is cut, the bolt retracts. Perfect for securing cabinets, doors, safes, etc

This lock can be directly connected to your Access Control System Controller. If you are building your own controller using custom PLC, Arduino, Raspberry Pi, or any other microcontroller, then you can use one of our compatible relay or MOSFET Modules to control this bolt lock from your microcontroller.

The bolt lock also comes with an adjustable timer. The timer activates the bolt lock automatically after detecting a door close after a preset delay. Three-time delays are available - 0,3 and 6 seconds. The required delay can be selected by the onboard slide switch

Applications:

  • These products are widely applied in access control systems and related applications
  • It is especially suitable for cabinets, drawers, small type doors
  • Can be used in Home Automation Systems
  • Glass Door, Shutter Locks, etc
  • This door lock is special in design with durable material. It can protect your home or business shops.

Product Features

  • Long Life: Upto 1,00,000 life cycles
  • Working Voltage: 12V DC
  • Working Current: 450mA
  • Especially suitable for glass doors
  • It is made from durable and high aluminum alloy material, built for durable use
  • Special circuit design, the door will unlock as long as the power is cut off
  • With no external interference, making it more stable and safer
  • Supports adjustable 0, 3, 6 seconds time delay
  • 100% brand new and high quality
  • Secure mode: NC model (Locked when power on, unlocked when power off)
  • Mini style, suitable for cabinet, drawer, small type door, and wooden, iron, glass door.
  • Aluminum alloy case, very strong and durable.
  • Can be opened by push button, remote controller, etc.
  • Lock Size: Approx. 7.91*1.38*1.61in / 201*35*41mm

  • Plate Size: Approx. 3.62*1.02*0.12in / 92*26*3mm

  • Bolt Size: 15mm diameter; 15mm extending length
  • Suitable for: Wooden Door, Glass Door, Metal Door, Fire-proof Door.

Package Includes:

  • 1x Magnetic Door Lock main body 60kg Strong Force
  • 1x Armature faceplate
  • 1x package Mounting hardware kit
More Information
Technical Details



Pinout

Wire Color Function
Red 12V Positive Power Supply
Black GND Negative Power Supply



Connection
