Closed End Wire Crimp Cap Connector Assortment Kit with Storage Box 40-Piece

Specifications:

• Product Type: Closed-End Wire Crimp Terminal Caps
• Quantity: 40 Pieces
• Insulation Material: Nylon (Translucent)
• Wire Gauge Compatibility: 22 AWG to 14 AWG
• Maximum Operating Temperature: 105°C
• Connection Method: Mechanical crimping (requires crimping tool)
• Storage: Included transparent plastic organizer box

Minimum hardware to get started:

• Wire Stripping Tool : to cleanly remove the outer insulation without snipping the internal copper strands.
• Crimping Pliers : you must use a mechanical crimping tool (not standard flat pliers) to crush the internal metal barrel securely without piercing the nylon insulator.

Safety Warnings:

• Voltage & Current Limits: Do not exceed the 300V rating. Ensure the combined gauge of the wires you are splicing fits comfortably within the cap's rated capacity (typically 22-14 AWG).
• Insulation Risk: Ensure no bare copper wire is exposed beneath the nylon skirt after insertion. All exposed copper must sit completely inside the internal metal tube.

Accessories
Included in the Box:

• 40× Closed-End Wire Crimp Caps
• 1× Transparent Plastic Organizer Box

Frequently Asked Question

• Is this 40-piece wire crimp cap set compatible with solid core wires?
  Yes, it can be used to securely join both solid core and multi-strand copper wires.
• Can I use these crimp caps for automotive 12V wiring?
  Yes, they are highly resistant to the vibrations commonly found in automotive environments.
• Do these crimp caps work for 240V AC mains wiring?
  We recommend them for DC electronics and low-voltage applications up to 300V maximum.
• What wire gauge (AWG) is compatible with these caps?
  They comfortably fit combined wire gauges ranging from roughly 22 AWG to 14 AWG depending on the strand count.
• What is the maximum voltage rating for these crimp caps?
  The translucent nylon insulation is rated to safely handle electrical systems up to 300V.
• Can these handle high current applications like motor wiring?
  The current capacity depends entirely on the gauge of the wire you are using, as the crimp provides a direct metal-to-metal connection.
• What is the maximum operating temperature for these connectors?
  The nylon skirt can safely withstand operating temperatures up to 105°C before degrading.
• How do I properly insert wires into the crimp cap?
  Strip about 10mm of insulation, twist the bare copper wires together, and push them fully into the internal metal barrel.
• Do I need a special tool to install these caps?
  Yes, you must use a mechanical crimping tool to properly crush the internal barrel without piercing the outer nylon shell.
• Can I reuse a crimp cap if I make a mistake?
  No, mechanical crimping permanently deforms the internal metal sleeve, so you must cut the wire and use a new cap.
• Which crimping tool should I use for these closed-end caps?
  A standard non-insulated terminal crimper with a crushing jaw is ideal for these specific connectors.
• Is there a specific technique to ensure a tight crimp?
  Ensure the crimper jaws are centered directly over the internal metal barrel before applying maximum physical pressure.
• Where can I find guides on proper wire crimping?
  You can search YouTube for standard closed-end crimp cap tutorials to see the technique in action.
