ATmega32U4 Pro Micro Development Board 5V 16MHz Type-C USB Module

Specifications

• Microcontroller: ATmega32U4
• Operating Voltage: 5V DC
• Clock Speed: 16 MHz
• Flash: 32KB
• SRAM: 2.5KB
• USB Interface: Type-C USB (Native USB support)
• Digital I/O Pins: 12 (including 5 PWM channels)
• Analog Input Channels: 4 x 10-bit ADC (Plus additional multiplexed pins)
• Hardware Serial: Rx and Tx connections
• Input Voltage (RAW): 6V to 9V DC recommended
• Dimensions: Approx. 33mm x 18mm
• Protection: On-board PTC fuse and diode protection for USB power

Applications

• Custom Peripherals: DIY mechanical keyboards, macro pads, and shortcut arrays.
• Simulators: Flight simulator panels and custom racing sim button boxes.
• Hardware Automation: Automated keystroke injection for testing or security protocols.
• Wearable Tech: Compact enough to be sewn into cosplay or wearable electronics.

Features:

• ATmega32U4 Microcontroller- 8-bit, 16MHz, 32KB Flash, 2.5KB SRAM, 1KB EEPROM.
• Type-C USB Connector for power and USB communication with the host.
• Compact Size ideal for space-constrained projects.
• Multiple digital, analogue, and power pins for sensors and components.
• Built-in USB Functionality: Direct USB device recognition for HID projects.
• Easily programmable via Arduino IDE.
• Powered via Type-C USB or RAW input pin with onboard voltage regulator.
• Built-in LEDs for debugging and status monitoring.

Unlock New Capabilities

• If you've mastered: Basic LED blinking and sensor reading with an Arduino Uno or Nano...
• This board unlocks: Native USB HID (Human Interface Device) capabilities. You can now write code that physically controls your PC, typing strings of text or moving the mouse cursor automatically!
• Effort/Requirements: Intermediate. You will need basic soldering skills to attach the header pins and an understanding of the Arduino Keyboard.h and Mouse.h libraries.

Virtual Technician & Wiring Guide

• ⚠️ Crucial Safety Warning: Backed by our Probots™ Logic-Safe guidelines, please note that this is a 5V logic board. Do NOT connect 3.3V-only sensors (like standard ESP8266 modules or modern 3.3V IMUs) directly to the data pins without a logic level converter, or you will damage the sensors!

Basic Pinout Guide:

• RAW: Unregulated power input (Apply 6V-9V here if not using USB power).
• VCC: 5V regulated power output (Do not input power here if using USB/RAW).
• GND: Ground connections.
• TX0 / RX1: Hardware serial pins (TTL level).
• Digital I/O Pins:  2, 3, 4, 5, 6, 7, 8, 9, 10, 14, 15, 16
• Dedicated Analog Inputs: A0, A1, A2, A3

Package Includes:

• 1 x ATmega32U4 Pro Micro Development Board  Type-C USB Module

Frequently Asked Questions (FAQ)

• Is this board an exact replacement for the Arduino Leonardo?
  Yes, it uses the same ATmega32U4 chip and acts identically in software, just in a significantly smaller form factor.
• Which board do I select in the Arduino IDE?
  Select "Arduino Leonardo" or "Arduino Micro". If you have the SparkFun AVR boards package installed, select "SparkFun Pro Micro" and ensure you choose the 5V/16MHz version.
• Does this board come with headers soldered?
  No, the board comes with unsoldered male header pins to allow for flush mounting or custom wire soldering.
• Why isn't my computer recognizing the board?
  Ensure you are using a USB Type-C Data cable, not just a charging cable. Also, try double-tapping the reset pin to GND to force bootloader mode.
• Can I power this via the RAW pin and USB at the same time?
  It is generally safe as there is a protection diode, but it's best practice to disconnect external RAW power when programming via USB to prevent voltage regulation conflicts.
• What is the maximum voltage I can apply to the RAW pin?
  While the regulator can handle up to 12V, we strongly recommend keeping it between 6V and 9V to prevent thermal overload on the tiny onboard regulator.
• Can I use this for a custom split mechanical keyboard?
  Absolutely. The Pro Micro is the industry standard for split keyboards like the Corne or Lily58 using QMK firmware.
• Is this the 5V or 3.3V version?
  This is the 5V / 16MHz version.
• How do I reset the board?
  There is no button! You must momentarily short the "RST" pin to the "GND" pin using a jumper wire or tweezers.
• What do the LEDs on the board indicate?
  Typically, there is a red power LED and two RX/TX indicator LEDs that flash during USB communication.
• Can I program this with AVR-GCC and AVRDUDE directly?
  Yes, the board comes pre-loaded with the standard Caterina bootloader, compatible with AVRDUDE via the AVR109 protocol.
• Why did my board stop showing up in the COM ports after a bad upload?
  You likely crashed the USB stack in your code. Double-tap Reset to GND quickly; the board will appear as a COM port for 8 seconds, giving you time to upload a blank sketch.
• Are the pins breadboard compatible?
  Yes, once you solder the included header pins, the board fits perfectly onto a standard 2.54mm pitch breadboard.
• Can it output 3.3V for my sensors?
  No, this board does not have a 3.3V regulator onboard. You will need an external step-down module.
• How much current can the VCC pin supply?
  When powered via USB, it can supply up to 500mA (limited by the USB port's capability and the PTC fuse).
• Does this support QMK and KMK firmware?
  It fully supports QMK (C-based). However, KMK requires CircuitPython, which requires an ARM chip (like the RP2040); the ATmega32U4 cannot run KMK.
• What is the difference between this and an Arduino Nano?
  The Nano uses the ATmega328P and requires a separate USB-to-Serial chip (like CH340). This Pro Micro uses the ATmega32U4 with native USB built directly into the silicon.
• Can I use PWM on this board?
  Yes, there are 5 hardware PWM pins available (Pins 3, 5, 6, 9, 10).
• How much flash memory is available for my code?
  The ATmega32U4 has 32KB of flash memory, of which 4KB is used by the bootloader, leaving 28KB for your sketches.
• Does the Type-C port support fast charging protocols?
  No, the Type-C port is strictly wired for USB 2.0 data and standard 5V power delivery (with 5.1k pull-down resistors for basic Type-C compatibility).
