Chint NC1-1210 3 Pole AC Contactors 240V

₹865.00 ₹ 733.05 + 131.95 GST
In stock
SKU
PRO3044
AC Contactors are used for high-power applications. The main contacts of AC contactors are generally NO contacts, and the auxiliary contacts are either NO or NC for Feedback.
Feedback contacts NO and NC refer to the state of the contacts before the electromagnetic system is energized. That is, the NO contact means that when the coil is not energized, its moving and static contacts are in an open state, and the coil is closed after it is energized. NC contact means that when the coil is not energized, its moving and static contacts are closed, and when the coil is energized, it is disconnected. Feedback can be used in the form of signal inputs to PLC or drive the indicators such as illumination, hooters, etc.AC Contactors allow a lower voltage and current to switch a much higher power circuit, so they are generally larger and more heavy-duty than control relays, Specially designed for remote making & breaking circuits to protect circuits from overload when assembling with a thermal overload relay. Maximum allowable current up to 12Amps, and is able to readily and frequently turn on or off the power supply for high-current power appliance, e.g. 240 V AC Input.

General Description:

Parameter Description
Electric ratings AC50/60Hz, 240V, 12A
Utilization category AC-3
Altitude 2000m
Ambient temperature -5 Degree C ~+40 Degree C
Mounting category III
Mounting conditions Inclination between the mounting plane and the vertical plane should not exceed 5
Standard IEC/EN 60947-4-1


Package Includes:
  • 1 x AC CONTACTORS CHINT NC1-1210 3P 240V

* Product Images are shown for illustrative purposes only and may differ from actual product.
More Information
Technical Details

Specifications:

Parameter Description
Pole 3.0
Rated Coil Voltage 240V AC
Input Contacts 3NO
Auxiliary contacts 1NO
Frequency 50/60 Hz
Rating AMP 12 Amp
kW Rating 4
Electrical life ( x 10^3Operations) 1000
Mechanical Lifetime(x 10^6) 10
