500X Handheld Digital Microscope with 2" IPS Screen - Portable Electronic Magnifier for PCB Inspection

Specifications

• Magnification: 500X (Digital Zoom)
• Display: 2.0-inch IPS High-Definition Screen
• Resolution: 2MP (1920x1080 Interpolated)
• Light Source: 8 Adjustable High-Intensity LEDs
• Focus Range: Manual Focus (0mm to 40mm)
• Battery: Built-in 600mAh Rechargeable Lithium-ion
• Working Time: Approx. 1.5 - 2 Hours continuous use
• Charging Port: USB Type-C (5V 1A)
• Material: ABS Industrial Plastic + Optical Lens

Applications

• Electronics & PCB Repair: Indispensable for identifying cold solder joints, microscopic short circuits (solder bridges), and reading laser markings on tiny ICs like 0402 resistors or QFN packages.
• Quality Control & manufacturing: Used by production line managers to quickly spot-check surface finishes, textile weaving defects, or printing offsets without slowing down the line.
• Educational & Biological Observation: Perfect for STEM education. Students can observe plant cells, insect structures, and mineral textures directly in the classroom without fighting for time on a single desktop computer.

Project Evolution

From Jeweler's Loupe to Digital Analysis If you have mastered basic soldering using a magnifying lamp or eye loupe, you know the fatigue that comes with it.

• The Upgrade: This microscope unlocks "Posture-Independent Inspection." You no longer need to bend your neck to the table; you bring the screen to your eye level.
• New Capability: Identify Counterfeit Components. The high magnification allows you to see the sanding marks or re-printing on "refurbished" chips that look new to the naked eye.
• Effort Level: Beginner. No software to install. Turn it on, focus, and view.

Virtual Technician:
      Usage & Safety Guide

• Focusing Tip: The focus wheel is sensitive. For high magnification, place the clear plastic cowl directly against the object (or very close) and turn the wheel slowly.
• Charging Warning: Use a standard 5V 1A charger. Do not use high-wattage "Fast Chargers" (like 65W laptop chargers) as they may damage the internal charging circuit.
• Lens Care: Avoid touching the lens glass with fingers. Clean only with the provided microfiber cloth or an optical lens wipe.

Package Includes:

• 1x Handheld Digital Microscope
• 1x USB Type-C Charging Cable
• 1x User Manual

Frequently Asked Questions (Technical FAQs)

• Can I save images to an SD card?
  No, this specific model is a live-view inspection tool designed for real-time observation. It does not have an SD card slot for recording.
• Does this microscope connect to a PC via USB?
  No, it is a standalone unit. The USB port is strictly for charging the internal battery.
• What is the actual battery life on a full charge?
  You can expect approximately 1.5 to 2 hours of continuous use with the LEDs at medium brightness.
• Can I use it while it is charging?
  Yes, pass-through charging is supported, allowing you to use it on a workbench indefinitely.
• Is the magnification really 500X?
  The 500X figure refers to the maximum digital magnification relative to a standard sensor size. For practical PCB work, it provides excellent clarity for component level inspection.
• What is the minimum focus distance?
  The microscope can focus right up to the object (0mm distance) when the plastic guard touches the surface.
• Is the screen visible outdoors?
  Yes, the IPS panel is bright enough for outdoor use, though direct sunlight should be shaded for the best contrast.
• Can I replace the battery?
  The battery is internal and non-replaceable. However, lithium batteries typically last for several years of regular use.
• Does it have a built-in light?
  Yes, it features a ring of 8 adjustable LEDs around the lens to illuminate the subject evenly.
• How do I adjust the brightness?
  There is a dedicated brightness control wheel or button on the side of the unit.
• Is this suitable for soldering under?
  It is primarily for inspection. Soldering directly under it is difficult due to the limited working distance (clearance) for the soldering iron.
• What implies "IPS" screen?
  IPS (In-Plane Switching) screens offer wider viewing angles and better color reproduction than cheaper TFT screens, meaning the image doesn't wash out when viewed from the side.
• Can it inspect 0201 SMD components?
  Yes, at max magnification, 0201 components are clearly visible and solder joints can be inspected.
• Is the stand included?
  No, this is a handheld unit. It is designed to be held or rested directly on the object.
• Does it work for coin collection?
  Yes, it is excellent for viewing mint marks, scratches, and details on coins.
• How long does it take to charge?
  It typically takes about 2 hours to charge fully from a standard 5V 1A USB port.
• Is the device water-resistant?
  No, it is not waterproof. Do not use it in wet environments or submerge the lens.
• Can I use it for textile thread counting?
  Yes, the magnification is sufficient to count threads and inspect weave patterns.
• Does it have digital zoom?
  The magnification is adjusted optically via the focus wheel/distance, not a digital pinch-to-zoom.
• Why is the image blurry?
  Blurry images are usually due to being too far from the object or moving the unit. Place the unit steadily on the object and adjust the focus wheel slowly.
