Helping Hand Soldering Station - Bifocal Magnifier, 2 LEDs & Iron Stand

Specifications

• Model Designation: TE-801

• Magnifier Type: Bifocal (Main lens with smaller high-magnification inset)

• Illumination Source: 2x White LEDs

• Lighting Adjustment: Flexible Metal Hose

• Clamping Mechanism: 2x Fully Articulated Auxiliary Crocodile Clips

• Soldering Iron Stand: Integrated Coiled Spring Holder (Welding Frame)

• Power Source: 3x AAA Batteries (Not included)

• Battery Life: Continuously discharge for more than 10 hours

• Base Construction: Weighted Pedestal with bottom battery compartment and steel plate for enhanced stability

Key Applications and Projects

• Drone / UAV Assembly: Holding flight controllers and ESCs securely while soldering thick 12AWG battery wires.

• Micro-Electronics Repair: Utilizing the bifocal magnifying glass to inspect and repair damaged traces on a motherboard.

• Model Making & Crafting: Providing a stable, illuminated, and magnified work area for painting miniatures or assembling scale models, explicitly noted as a useful aid for model makers.

Unlock New Capabilities (Project Evolution) The Portable Field-Repair Station: Because the TE-801 is entirely powered by 3x AAA batteries and requires no AC wall adapter, it is the ultimate field companion. Evolve your RC or drone racing kit! Pack this helping hand alongside a portable, battery-powered smart soldering iron (like a Pinecil or TS100) and a portable power bank. If you snap a wire or burn out an ESC during a race in the middle of a field, you can set up a fully illuminated, magnified, and stabilised repair station on the tailgate of your car and get back in the air in minutes.

PACKAGE INCLUDED

• 1 x Weighted Pedestal Base with lifting knob and horizontal crossbar

• 2 x Adjustable Auxiliary Crocodile Holding Clamps

• 1 x Bifocal Magnifying Glass Piece attached to a Flexible Metal Hose

• 1 x Coiled Soldering Iron Holder (Welding Frame)

• (Note: 3x AAA batteries required for the LED lights are not included)

FREQUENTLY ASKED QUESTIONS (FAQ)

1. What is the exact model number of this helping hand tool? This tool is designated as the TE-801 Helping Hand Magnifier.

2. How are the LED lights powered? The LED lights are powered entirely by 3 pieces of AAA batteries.

3. Are the batteries included in the package? No, the installation of the 3 batteries is required, and they are not included with the product.

4. Where do the batteries go? There is a battery compartment located on the bottom of the pedestal base with a removable plastic cover.

5. How many LED lights does this model have? This specific model features a 2 LED light source integrated into the magnifying glass housing.

6. How do I turn the lights on and off? There is a push-button light switch located directly on top of the magnifying glass piece.

7. Can I plug this into the wall with an AC adapter? No, the TE-801 model is strictly designed for cordless operation using AAA batteries and does not feature an AC input jack.

8. How long will the batteries last? With three AAA batteries, the large capacity of this model allows it to continuously discharge and provide lighting for more than 10 hours.

9. Can I use this tool in the dark? Yes, the packaging notes that with the two LED lights, this model can work very well in a dark environment.

10. Is the magnifying glass adjustable? Yes, the magnifying glass piece is attached to a flexible metal hose, allowing you to bend and position it exactly where you need it.

11. Does the magnifying glass have different zoom levels? Yes, it features a bifocal design. The large main lens has a smaller, higher-magnification circular lens inset near the bottom edge for extremely detailed work.

12. What is the coiled metal spring used for? That component is a "welding frame" (soldering iron stand) designed to provide a safe, heat-resistant place to rest your hot soldering iron when not actively in use.

13. Are the holding clips adjustable? Yes, the auxiliary crocodile holding clamps are fully adjustable using the provided thumb screws.

14. Can the height of the clips be adjusted? Yes, there is a lifting knob located on the main vertical pillar that allows you to raise or lower the horizontal arm holding the clips.

15. Will the alligator clips scratch my circuit board? Bare metal crocodile clips can sometimes scratch delicate traces. It is a common professional practice to slide a small piece of heat-shrink tubing over the teeth to create a soft, non-marring grip.

16. What prevents the tool from tipping over during use? The tool features a bottom battery compartment furnished with a steel plate, which significantly enhances the stability of the pedestal base.

17. Is this tool only intended for soldering? No, while it is perfect for electronics, it is also explicitly advertised as a useful aid for model makers and craft hobbyists.

18. Is the soldering iron stand removable? Yes, the welding frame is bolted onto the main assembly and can be adjusted or removed if you only wish to use the magnifier and clips.

19. Do I need any special tools to assemble it out of the box? No, all the necessary adjustments and assembly can be done by hand using the integrated thumb screws and lifting knob.

20. Does the flexible metal hose stay in place once bent? Yes, the heavy-duty metal hose is designed to be stiff enough to hold the weight of the magnifying glass and LED housing securely in whatever position you bend it into.
