S500 Quadcopter Frame PCB Version - Blue/Black Arms with Blue Landing Gear DIY KIt

Specifications

• Wheelbase: 500mm

• Mainplate Type: Integrated PCB (Power Distribution Board)

• Arm Material: Carbon-Fiber Reinforced Plastic (2 Blue, 2 Black)

• Landing Gear Material: High-Impact Plastic (Blue)

• Landing Gear Height: 190mm total (150mm vertical clearance)

• Landing Gear Width: 234mm (at base)

• Recommended Propellers: 10 to 12 Inch

• Recommended Motors: 2212, 2216, 2808 series

Key Applications & Projects

• Aerial Photography: The high-clearance landing gear is specifically designed to accommodate GoPro-sized gimbals.

• Autonomous Flight: Spacious centre deck for mounting GPS-enabled flight controllers like the Pixhawk or APM.

• Training Platform: Durable, easy-to-repair construction makes it ideal for intermediate pilots learning multi-rotor dynamics.

Unlock New Capabilities (Project Evolution)

• Feature Upgrade: The upward-swept arm design acts like a "dihedral" wing on a plane, providing natural self-levelling stability that is superior to flat-arm drone frames.

• Effort Level: Intermediate. Requires soldering ESCs and power leads to the integrated PCB mainplate.

Package Includes:

• 1 x S500 PCB Top Plate

• 1 x S500 PCB Bottom Plate (Integrated PDB)

• 2 x Blue Reinforced Plastic Arms

• 2 x Black Reinforced Plastic Arms

• 2 x Blue High-Clearance Landing Gear Skids

• 1 x Full Assembly Hardware Kit (Screws & Standoffs)

FREQUENTLY ASKED QUESTIONS (FAQ)

1. What is the "PCB Version"? It means the bottom plate has integrated copper tracks for power distribution, so you don't need a separate PDB board.

2. What motor size is best? The frame is optimized for 2212 or 2216 motors (900KV–1000KV).

3. Does it include motors or ESCs? No, this is the frame and landing gear kit only.

4. What size propellers can I use? It fits 10-inch to 12-inch propellers comfortably.

5. How high is the landing gear? The total height from the ground to the top of the mount is 190mm.

6. Will a gimbal fit underneath? Yes, there is 150mm of vertical clearance and a 234mm width between the skids.

7. What battery size fits? Standard 3S or 4S 2200mAh to 5000mAh LiPo batteries are recommended.

8. How do I tell the front from the back? Most pilots use the blue arms as the front to aid in visual orientation.

9. Are the arms swept upward? Yes, the S500 design features slightly swept-up arms for added stability.

10. Is it compatible with Pixhawk? Yes, the center plates have standard mounting holes for most flight controllers.

11. What is the material of the arms? They are made of high-strength, carbon-fiber reinforced plastic.

12. Can I use 6S batteries? Yes, as long as your electronics (motors/ESCs) support 6S voltage.

13. Are replacement arms available? Yes, S500 arms are a standard spare part and easily replaceable.

14. How do I mount the battery? It includes a battery mounting plate that sits between the center frame and landing gear.

15. Does it require soldering? Yes, you must solder your ESC power wires to the PCB mainplate.

16. What is the weight of the frame? Approximately 450 grams including landing gear.

17. Is the landing gear flexible? It is made of high-impact plastic designed to absorb some shock during landing.

18. What is the wheelbase? The diagonal distance from motor to motor is 500mm.

19. Does it include a battery strap? Standard kits usually include one, but please check the specific package list.

20. Can I mount a GPS on this? Yes, it is a very popular frame for GPS-assisted autonomous builds.
