Description:

This is an RS232 to TTL Converter Adaptor Module Board called MAX3232 that is used for the electrical level converter.

The RS232 to TTL 5V Signal Converter Module(MAX3232) is a professional module for projects requiring PC/Laptop RS232 interface to 5V TTL logic. This module converts signals between RS232 voltage levels and TTL voltage levels.

It is bi-directional, where TTL signals are converted to RS232 levels and RS232 levels are converted to TTL levels. It is ideal for use in pc interfacing, microcontroller-based projects, robotics, or for experimental and educational purposes.

Specifications:

High speed, replaceable MAX232 based. The device fitted supports up to 120kbps
Works with PCs or Laptops
Supports microcontroller UARTs – 5V TTL signal levels.
Single DC supply: wide input range for 4201 or 5V for 4202 and 4203
Small PCB footprint of 50´40mm
Low current status LED(s)
Very low power consumption
Optional onboard PSU for internal/external use for a quick start out of the box.
Power can be routed to pin 9 (if required) on the RS232 connector – useful for specific
applications.

Package Includes:

1 x RS232 - TTL Module MAX3232
