ProMax 19mm Push Button Switch Socket Connector 5-pin Wire Harness for Metal Switches

Specifications:

• Compatibility: Standard 19mm Metal Push Button Switches (5-Pin).

• Interface: 5-Pin female socket (NO, NC, C, LED+, LED-).

• Wire Length: ~150mm (15cm) pigtail.

• Housing: High-temperature engineering thermoplastic.

• Switch Operation type: Latching/Momentary.

Key Applications

• Marine & Automotive Dashboards: Create a professional, vibration-resistant wiring harness for 19mm dash switches.

• Industrial Control Units: Simplify machine start/stop stations where switches might need periodic replacement.

• High-End PC Modding: Connect 19mm vandal-resistant power buttons without bulky solder joints interfering with cable management.

• Security Systems: Clean wiring for emergency override buttons and bypass switches.

Project Evolution

• Past Projects: If you have previously used 12mm or 16mm buttons, you know how cramped the wiring becomes as you scale up.

• Feature Upgrade: The 19mm connector allows you to move into "Production Grade" building. It enables a modular architecture where the switch is a user-replaceable component rather than a permanent solder point.

• Effort Level: Beginner. Just plug it in and connect the pre-stripped wires to your controller or power source.

Virtual Technician & Wiring
⚠️ Pro Tip: Always use a multimeter to verify your switch's internal mapping before applying high-voltage AC.

 5-Pin Mapping for ProMax 19mm:

• Red/Black: Usually assigned to LED Power (+ and -).
• White: Common (C)
• Blue: Normally Closed (NC).
• Green: Normally Open (NO)

Package Includes:

1 X ProMax 19mm Push Button Switch Socket Connector 5-pin Wire Harness for Metal Switches

Frequently Asked Questions (FAQ)

1. Does this fit 16mm or 22mm switches?
   No, this is specifically sized for 19mm switch terminals.
2. Is the socket orientation reversible?
   No, it is keyed to fit the switch pins in only one correct orientation.
3. Can I use this for 24V LED switches?
   Yes, the socket only passes the voltage; ensure your switch has the correct internal resistor.
4. Are the wires thick enough for a 5A load?
   Yes, the 20AWG leads are rated for standard industrial switch loads.
5. What if my switch only has 3 pins?
   This 5-pin socket will not fit 3-pin switches; it is designed for illuminated 5-pin models.
6. Can I remove the pigtails to use my own wire?
   The pins are locked into the housing; we recommend splicing onto the existing 15cm leads.
7. Is the connector flame retardant?
   Yes
8. Does the socket lock onto the switch?
   Yes, it uses a friction-lock design that resists vibration.
9. Can I use this for AC mains switching?
   Yes, provided your switch and insulation (heat shrink) are rated for it.
10. How do I identify the "Normally Open" wire?
    We recommend checking the pin labels on the switch base; the socket aligns directly with them.
11. Do I need a special tool to install it?
    No tools required—just hand pressure to snap it onto the switch.
12. Are the wire ends pre-tinned?
    They are pre-stripped for your convenience.
13. Will this work with latching switches?
    Yes, it works with both momentary and latching 19mm 5-pin switches.
14. Is it UV resistant?
    The housing is designed for internal panel use; avoid direct long-term sunlight exposure.
15. What is the spacing between the pins?
    It follows the standard 19mm industrial terminal footprint.
16. Is it compatible with RGB 19mm switches?
    No, RGB switches usually require 6 pins; this is for single-color (5-pin) switches.
17. Does it include the mounting nut for the switch?
    No, that comes with the switch itself.
18. Can I use this in high-heat environments?
    It is rated for standard industrial temperatures (-20°C to +85°C).
19. What happens if I cross the LED wires?
    Most modern LEDs have protection, but they simply won't light up.
20. Is this sold as a pair?
    No, this is a single unit price.
