GP2Y0A710K0F Proximity Distance Measuring Sensor Sharp

Description:

Sharp GP2Y0A710K0F is a distance measuring sensor unit, composed of an integrated combination of PSD (position sensitive detector), IRED (infrared emitting diode), and a signal processing circuit. The variety of the reflectivity of the object, the environmental temperature, and the operating duration are not influenced easily to distance detection because of adopting the triangulation method. This device outputs the voltage corresponding to the detection distance. So this sensor can also be used as a proximity sensor.

Note:  In the Sharp sensors there are different models, with each model comes a different sensing range. Surf our website to find the sharp sensor that suits your project

Features:

• Supply voltage: 4.5 to 5.5 V
• Distance measuring range: 100 to 550 cm
• Analog output type
• Package size: 58×17.6×22.5 mm
• Consumption current: Typ. 30 mA

Applications:
1. Projector (for autofocus)
2. Robot cleaner
3. Auto-switch for illumination, etc.
4. Human body detector
5. Amusement equipment
(Robot, Arcade game machine)

Package Includes :

1 x Proximity Distance Measuring Sensor Sharp - GP2Y0A710K0F

1 x Connecting Cable.
