VL53L3CX Time-of-Flight Multi-Target Distance Sensor

₹699.00 Rs. 592.37 + 106.63 GST
In stock. 1-7 Day Delivery in India.
SKU
PRO2196

Description:

The VL53L3CX is the latest Time-of-Flight (ToF) product and embeds third-generation FlightSense patented technology. It combines high-performance proximity and ranging sensor, with multi-target distance measurements and automatic smudge correction. The miniature reflowable package integrates a single-photon avalanche diode (SPAD) array and physical infrared filters to achieve the best-ranging performance in various ambient lighting conditions, with a wide range of cover glass windows.

The VL53L3CX combines the benefits of a high-performance proximity sensor, with excellent short distance linearity, together with ranging capability up to 3 m.
With patented algorithms and ingenious module construction, the VL53L3CX is also able to detect different objects within the field of view (FoV) with depth understanding.

Specifications:

  • Resolution: 1 mm
  • Maximum range: 3M
  • Interface: I²C
  • Minimum operating voltage: 2.6 V
  • Maximum operating voltage: 5.5 V

Applications:

  • Service robots and vacuum cleaners (wall following and fast obstacle detection)
  • Sanitary (robust user detection whatever the target reflectance)
  • Smart buildings and smart lighting (user detection to wake up devices)
  • IoT (user and object detection)
  • Laser-assisted autofocus (AF): enhances the camera AF system speed and robustness, especially in difficult scenes (low light and low contrast); ideal companion for phase-detection autofocus (PDAF) sensors
  • Video focus tracking assistance

Package Includes:

1 x VL53L3CX Time-of-Flight Multi-Target Distance Sensor
