Analog TDS Water Conductivity Sensor Waterproof Module

Description:

TDS (Total Dissolved Solids) Water Conductivity Sensor indicates that how many milligrams of soluble solids dissolved in one liter of water. In general, the higher the TDS value, the more soluble solids dissolved in water, and the less clean the water is. Therefore, the TDS value can be used as one of the references for reflecting the cleanliness of the water. These analog TDS sensor kits are compatible with Arduino, plug & play, and easy to use. Matching with an Arduino controller, you can build a TDS detector easily to measure the TDS value of liquid.

This product supports 3.3 ~ 5.5V wide voltage input, and 0 ~ 2.3V analog voltage output, which makes it compatible with a 5V or 3.3V control system or board. The excitation source is an AC signal, which can effectively prevent the probe from polarization and prolong the life of the probe, meanwhile, increase the stability of the output signal. The TDS probe is waterproof, it can be immersed in water for long time measurement.

Specifications:

• Supply Voltage: 3.3 ~ 5.5V
• Output Signal: 0 ~ 2.3V
• Working Current: 3 ~ 6mA
• TDS Measuring Range: 0 ~ 1000ppm
• Number of pins in TDS Probe: 2
• Overall length: (approx) 60cm



Applications:

• Water Quality Monitoring
• Aquaculture
• Hydroponic & Aquaponic

Package Includes:

1 x Analog TDS Water Conductivity Sensor Waterproof Module
