Read Article →7" HMI Display offers a large industrial-grade display solution. HMI with Nextion Software makes it easy to deploy GUI applications with minimal programming.
Nextion NX8048T070-Generic 7.0″ HMI TFT LCD Touch Display is a seamless Human Machine Interface (HMI) solution that provides a control and visualization interface between a human and a process, machine, application or appliance. Nextion is mainly applied to the Internet of thing (IoT) or consumer electronics field. It is the best solution to replace the traditional LCD displays. Users quickly generate GUI Controls with minimal coding on the Nextion Editor. The microcontroller can then trigger these control using a simple UART interface.
Nextion includes a hardware part (a series of TFT boards) and a software part (the Nextion editor). The Nextion TFT board uses only one serial port to communicate. It lets users avoid the hassle of wiring. We noticed that most engineers spend a lot of time on application development but get unsatisfactory results. As a solution to this situation, the Nextion editor has mass components such as button, text, progress bar, slider, instrument panel etc. to enrich the interface design. Furthermore, the drag-and-drop function ensures that users spend less time in programming, which will reduce 99% of their development workloads. With the help of this WYSIWYG editor, designing a GUI is a piece of cake.
It’s easy to adapt Nextion family HMI to existing projects. Users just need to provide it with a UART.
Nextion 7.0” HMI TFT Screen Intelligent Display Module with integrated 4-wire Resistive Touch Panel For Arduino DIY NX8048T070 800×480 is a powerful 7.0” HMI, which is a member of the Nextion family. Features include: a 7.0″ TFT 800×480 resistive touchscreen display, 16M Flash, 2KByte RAM, 65k colors.
The Nextion Displays are also available in different sizes - 2.4”, 2.8“ 3.2”, 3.5”, 4.3”, 5.0”, 7.0”, with Resistive and Capacitive Touch Screens, with Enclosures, etc. Contact us directly for more details.
You can develop the HMI GUI project via the free Nextion Editor software, the easy Drag-and-Drop components and simple ASCII text based instructions will dramatically reduce your HMI project development workloads.
The Nextion solution is the best balance HMI solution between cost and benefit with low and decreased learning curve.
Features:
Applications
This display is perfect for applications where quick deployment is required. Users can quickly add a high resolution display using just a serial port.
Package Includes:
| Technical Details | Official Product Page: Datasheet, Dimensions, Manual |
|---|---|
| Display Type | TFT Color |
| Screen Size (inch) | 5-10 |
| Touch Screen | Yes |
| Interface: | HDMI |
| Controller | Nextion |
Probots sells every Electronics Part for your next Project. You can order 10,000+ Electronic Parts Online - Arduino, Raspberry Pi, NodeMCU Development Boards, Sensors, Motors, Motor Drivers, SMPS, Plastic Enclosures etc in India directly on probots.co.in
We delivery electronics components and parts throughout India using standard couriers like Bluedart, Delhivery & India Post.
For order related queries contact -
Probots sells every Electronics Part for your next Project. You can order 10,000+ Electronic Parts Online - Arduino, Raspberry Pi, NodeMCU Development Boards, Sensors, Motors, Motor Drivers, SMPS, Plastic Enclosures etc in India directly on probots.co.in
We offer specialized services for Bulk, Wholesale & B2B Customers like discounted prices, additional shipping options, customised products, etc . Customer with large quantity & regular orders qualify for the specialised discounted rates.
We also offer dedicated sales team to assist you with the order process by providing sales quotations, PI, technical support for choosing products, etc.
Note: Business Orders are processed manually and usually take 1-3 days to process compared to placing the order directly on our website. Please plan your purchases accordingly.
Need Help?
For bulk enquiries contact us by -
Probots Electronics is highly regarded for its great selection of components and professional service. Customers frequently praise the awesome care and timely delivery provided by the team to ensure all products arrive safely.
● 17 min readWelcome to Vol. 12 of The Probots Showdown. Three boards. Three price points. Three very different futures for your project.Should you stick with the
Read Article →
● 10 min read12 projects. One board. Zero excuses. From a radar scanner that maps your room to a voice-controlled robot car you command with your phone — this is w
Read Article →
● 20 min readIf you have outgrown the basic “blinky” boards but aren’t ready to spend hundreds of dollars on enterprise gear, the Tang Primer 25K
