YDLIDAR T5(hereinafter referred to as T5) is a 300-degree two-dimensional TOF (Time-of-Flight)rangefinder developed by the YDLIDAR team. With a single-line scanning design, T5 supports20Kpoint cloud data output per second and 15m distance measurement requirement. The compact appearance (~Γ70mm x 83mm) makes it easily integrate. 905nminfrared laser andself-developed signal processing algorithms can meet the needs of outdoor application scenarios. Also, YDLIDAR provides a complete integrated development interface, and point cloud datatransmission is carried out by network protocol. T5 is widely used in robot navigation and obstacle avoidance, environmental scanning andmapping, industrial AGV, assisted driving and other fields
Features:
5m ranging distance
ο Ranging frequency up to 20KHz
ο High Ranging distance repeatability
ο 300 degree omnidirectional scanning ranging distance measurement
ο Strong resistance to ambient light interference
ο 15-30Hz adaptive motor scanning frequency
ο IP Protection Level: IP65
ο 100M adaptive network interface for data transmission
1 x YDLIDAR T5 LIDAR SENSOR
| Sensor Technology | LiDAR / ToF (Time of Flight) |
|---|---|
| Scanning Type | 2D Sweeping (360Β°) |
| Max Measurement Range | Medium Range (1m to 5m) |
| Output Interface | Ethernet |
| Operating Environment | Industrial / Enclosed (Waterproof/IP65) |
| Manufacturer | YDLIDAR |
