TYPE-C USB to TTL Serial Port CH340 USB Module Development Board DC 5V/ 3.3V

₹159.00 Rs. 134.75 + 24.26 GST
In stock. 1-7 Day Delivery in India.
SKU
PRO3040

Product manual:

This product is a Type-C to TTL serial port module, using CH340 USB bus conversion chip, with 2 indicator lights on the board, which are communication indicators. Because there is no serial port on our current computer, we generally use a USB to serial port module, with only one purpose, to map the computer's USB port to a serial port.

Product parameters:

1.Working voltage: 5V or 3.3V
2.Default working voltage: 5V
3.Working temperature: -40°C~85°C
4.Baud rate: 50~2Mhz
5.Operating system: Windows xp, 7, 8, 10


ISP and communication:

Support STC MCU download program
Support STM8 download program with boothloader
Support Arduino download program with boothloader
Support STM32 serial port download program


Pin description:

V+VCC power supply positive input and output: when the working voltage
is 5V, it is the 5V power output, when the working voltage is 3.3V, it is connected to the external 3.3V power supply
V- GND Power negative pole: 0V
TX data sending end: connect to MCU or target board data receiving end RX data receiving end: connect to MCU or target board data sending end


Package Included:

CH340C module X1
