TY-610 PLCC Extractor - Harmless IC Extraction Tool for Mobile & Mainboard Repair

Specifications

• Tool Type: Manual Spring-Assisted PLCC Extractor

• Material: Reinforced ABS Handle with Stainless Steel Claws

• Claw Type: Dual-point hook system for corner engagement

• Color: Matte Black

• Compatibility: PLCC sockets (20-pin to 84-pin typically) and some socketed DIP packages

• Safety Feature: Non-marring contact points for motherboard protection

Key Applications & Projects

• Mobile Phone Repair: Removing BIOS or baseband chips from socketed mobile boards.

• Motherboard Maintenance: Swapping socketed BIOS chips or firmware ICs on older computer hardware.

• Prototype Testing: Ideal for swapping microcontrollers during the development of embedded systems.

Unlock New Capabilities (Project Evolution)

• Feature Upgrade: The "harmless" extraction design allows for the reuse of chips, making it an essential tool for component salvaging from donor boards.

• Effort Level: Beginner. Simply align the hooks with the notches in the socket corners and squeeze gently to lift.

Package Includes:

• 1 x TY-610 PLCC Extractor Chip IC Extraction Repair Tool Black

FREQUENTLY ASKED QUESTIONS (FAQ)

1. What is a PLCC extractor? It is a tool designed to pull Plastic Leaded Chip Carriers out of their sockets safely.

2. How does the TY-610 protect the mainboard? It uses hooks that lift the chip vertically, preventing the side-to-side prying that damages boards.

3. What does PLCC stand for? It stands for Plastic Leaded Chip Carrier.

4. Can it be used for DIP packages? While designed for PLCC, it can be used for some socketed DIP packages if the hooks can engage the ends.

5. Is the handle ESD-safe? The material is standard ABS; for sensitive environments, ensure you are grounded with an ESD strap.

6. How do I clean the tool? Use a lint-free cloth and 99% Isopropyl Alcohol to clean the steel claws.

7. What is the maximum IC size it can pull? It typically handles standard PLCC packages from 20 to 84 pins.

8. Why is the claw made of metal? Stainless steel provides the strength required to hook under tight-fitting chips without bending.

9. Is it suitable for laptop repair? Yes, it is excellent for removing socketed CMOS or BIOS chips in laptops.

10. Can it remove surface mount chips (SMD)? No, this is for socketed ICs only. Soldered SMD chips require a hot air station.

11. How do you maintain the spring tension? Avoid over-squeezing the handle when not in use to preserve the mechanical spring life.

12. Does it work on BIOS chips? Yes, it is the standard tool for removing socketed BIOS chips.

13. Is it safe for beginners? Yes, it is much safer than using a screwdriver to pry out chips.

14. What makes the TY-610 different from pliers? Pliers crush the IC casing; the TY-610 hooks the underside of the package for a safe lift.

15. Is it portable? Yes, it is lightweight and fits easily in any repair technician's toolkit.

16. Can it pull socketed ICs from breadboards? Yes, though it is primarily designed for high-density PLCC sockets.

17. Does the plastic handle provide grip? Yes, the handle features a textured grip to prevent slipping during extraction.

18. What is the weight? It is extremely light, weighing approximately 35 grams.

19. How do you align the claws? Insert the claws into the diagonal corner notches found on most PLCC sockets.

20. Does it require much force? No, the tool uses a squeeze mechanism that creates enough mechanical advantage to lift chips with minimal effort.
