16mm ProMax PPS16000NM-01R Metal Push Button Switch High Head Momentary

₹99.00 ₹ 83.9 + 15.1 GST
In stock
SKU
PRO3073

These are Industrial Grade high-quality switches in metal body from ProMax.This is an IP65-rated Switch for generic switch input, reset signals, etc. It can be panel-mounted and comes with a Flat Head on the front. Provides a premium quality look and feel after installation.



This Momentary Metal Pushbutton is a perfect choice if you are in need of a heavy-duty push-button. These metal push buttons are very tough, small, panel-mount momentary switches. It is an SPDT with 16mm threading. This button is perfect for basic On/Off functions. Comes with screw terminal pins for easy connection. These momentary buttons are rated up to 3A and 250VAC.

Note: We can carefully manufacture this switch with the best quality contacts, springs and metal case. This is not a low-cost switch with false output ratings. Use only ProMax Industrial grade switches for the best quality and life.

Features:

  • Brand: ProMax
  • Model No: PPS16000NM-10R
  • Panel Mount Industrial Switches Push Button
  • Switch Thread Size: 16mm
  • No of Poles: 1 Poles - Each pole has C & NO
  • Pin Termination: Screw Terminal
  • Switch Max. Load Rating: 250V 3A AC
  • Switch Operation MTBF: 50,000 cycles
  • Stainless Steel Body
  • IP65 Waterproof Rating
  • Tamper Resistant
  • Momentary Type Operation
  • Raised Head: The switch handle is raied from the body when the switch is off.

Applications:

  • These switches can replace most generic switches to offer a premium look and feel after panel mount installation
  • Can be used as main power control switch for On/Off Applicaitons
  • Can be used in medical and consumer products for main power control
  • Generic Settings or UI Input Switch
  • Great for electromagnetic starter, motor starter, etc
  • Relay Control Switch
  • Horn Button Switch
  • PC Power Switch or any circuit controls

Package Includes:

1x 16mm ProMax PPS16000NM-10R Metal Push Button Switch Waterproof Momentary



More Information
Technical Details





Operation TypeMomentary
LED VoltageNA
SwitchHeadShapeRaised Head
SwitchPoles1 Pole
IndicationColorNA
