Radar Motion Detector Sensor Microwave Doppler CDM324

Description:

CDM324 is a  24 GHz band single-channel radar transceiver.it uses a planar microstrip antenna structure, has an independent transmitting and receiving channels and a single IF output.it is mainly used for velocity information detection of short-range targets. These Radar sensors are used for detecting, locating, tracking, and recognizing objects of various kinds at considerable distances. It operates by transmitting electromagnetic energy toward objects, commonly referred to as targets, and observing the echoes returned from them.

 Specifications:

• Transmitting Frequency: 24 GHz
• Output Power: 16dbm
• Operating Current: 30MA, max: 40MA
• Operating Voltage: 5V
• Pulse Width: 10US
• IF Output: 300MV

Applications:

• Automatic Door Sensor
• Microwave Induction Switch
• Intelligent Light Control System
• Anti-Intrusion Detection
