Read Article βProMax Emergency Stop Switch is also known as Emergency Power Off Switch (EPO). These Push Buttons are Industrial grade and used as a safety measure to stop hazardous electrical loads in control panels and any electrical circuits.
ProMax PM150 Handheld Digital Oscilloscope Mini βΉ3,699.00
ProMax CSG01 Programmable 4-20mA Current Signal Generator with LCD Digital Display Back Light βΉ1,499.00
ProMax CSG02 Handheld Voltage & Current Generator DC 0-10V 4 to 20mA βΉ2,999.00
ProMax PSG01 PWM Signal Generator with Display βΉ499.00
ProMax CSG03 4-20ma Current & Voltage Signal Generator With Measuring βΉ7,999.00 Emergency stop switch is usually a manually controlled push switch (the button is red), press to lock and rotate clockwise to release the red mushroom head button switch, connect the control circuit of the equipment in series, used to directly disconnect the power of the control circuit in an emergency, to stop the equipment to avoid abnormal operation quickly.
This Latching Plastic Pushbutton is a perfect choice if you need a heavy-duty push-button. These Mushroom Head Plastic Emergency Stop push buttons are very tough, panel-mount latching switches with SPST Contacts.
This button is perfect for safety measures for quickly disconnecting electrical power to a particular piece of equipment, or to an entire facility, in the event of an emergency, 10A and 250VAC.
Emergency stop buttons are wired in series with the control circuit of machinery equipment. When pushing the mushroom head, the emergency stop button will break the circuit, which is connected through NC (Normally Closed)of connected equipment and remove the power supply that keeps the circuit energised and the same time alram indication(light or hooter) circuit will connect the circuit, which is connected through NO (Normally Opened)of connected equipment.
Note: This is a SPST Single-pole switch without an LED. It has one contact, with 1 pole consisting of C & NO, and another with C & NC terminals.
Specifications:
Package Includes: 1 x ProMax 22MM Emergency Stop Switch Plastic Mushroom Head NO NC Without LED


| Technical Details | Dimensions:
|
|---|---|
| Operation Type | Latching |
| Voltage | NA |
| Switch Head Shape | Mushroom Head |
| Switch Poles | 1 Pole |
| Indication Color | NA |
