ProMax19MM Emergency Stop Switch Mushroom Head Waterproof Metal 2 pole

Emergency stop switch is usually a manually controlled push switch (the button is red), press to lock and rotate to release the red mushroom head button switch, connect the control circuit of the equipment in series, used to directly disconnect the power of the control circuit in an emergency, to quickly stop the equipment to avoid abnormal operation.

This Latching Metal Pushbutton is a perfect choice if you are in need of a heavy-duty push-button. These Mushroom Head metal Emergency Stop push buttons are very tough, panel-mount latching switches. It is a DPDT with 19mm threading.

This button is perfect for safety measures for quickly disconnecting electrical power to a particular piece of equipment, or to an entire facility, in the event of an emergency. The overall length (including leads) is 2" and has small solder lugs for connection. These Latching buttons are rated up to 3A and 250VAC.

Note: We can carefully manufacture this switch with the best quality contacts, springs, and metal cases. This is not a low-cost switch with false output ratings. Use only ProMax Industrial grade switches for the best quality and life.

Emergency stop buttons are wired in series with the control circuit of machinery equipment. When pushing the mushroom head the emergency stop button will break the circuit of connected equipment and removes the power supply that keeps the circuit energized.

This is DPDT double-pole switch. It has two poles, each with its individual C, NO, and NC terminals. This allows you to control up to 2 devices or load wires independently. If you use a DPDT switch for input power or battery power input you can switch both power wires using this switch for complete power isolation when the switch is off. You may also connect two different loads with a Double pole switch.

Package Includes:

1 x ProMax 19MM Emergency Stop Switch Mushroom Head

THE PICTURES SHOWN HERE ARE FOR ILLUSTRATION PURPOSES ONLY.

Emergency Stop Switch Interface Guide:

1. The switch is locked, and the device starts. The switch is reset, and the device is turned off.

The wiring way is as follows: First step, the positive pole of the power is connected to the C pin of the switch, The second step, the negative pole of the power is connected to the negative pole of the device, in the third step, the positive pole of the device is connected to the NO of the switch.

2. The switch is locked, and the device is turned off. The switch reset, and the device starts

The wiring way is as follows: In the first step, the positive pole of the power is connected to the C pin of the switch, in the second step, the negative pole of the power is connected to the negative pole of the device, the third step, the positive pole of the device is connected to the NC of the switch.
