Case for Raspberry Pi B+ / Pi 2 / Pi 3 White and Red

Specifications

• Enclosure Type: 5-Part Modular Snap-Fit Case
• Material: High-grade, durable ABS Plastic
• Color Scheme: Two-tone White and Red (Pink inner top)
• Compatibility: Raspberry Pi 3 Model B/B+, Raspberry Pi 2 Model B, Raspberry Pi 1 Model B+
• Access Points: Full access to GPIO (via removable side panel), USB, Ethernet, 3.5mm Jack, HDMI, and Micro-USB Power.
• Camera/Display: Integrated routing slots for CSI Camera and DSI Display ribbon cables.
• Modifiability: Top lid and inner pink plate can be removed to accommodate various HAT heights.
• Stability: Includes anti-slip rubber feet for desktop traction.

Applications

• Modular Prototyping Stations: Swap between different sensor HATs without removing the Pi from its protective base.
• Retro Gaming Consoles (RetroPie): Keep the board safe from dust while looking sleek next to your TV.
• IoT Hubs & Home Assistant: A secure enclosure that won't block the Pi 3's onboard WiFi/Bluetooth signals.
• OctoPrint Servers: Protect your Pi from 3D printer debris while keeping camera ribbon cables neatly routed.

Unlock New Capabilities

• Past Projects: You've likely been running your Raspberry Pi bare on a desk, or using a basic 2-piece case that forces you to leave the lid off entirely if you want to connect a single jumper wire.
• Feature Upgrade: This modular case unlocks the ability to safely stack hardware. Use the custom "pink layer" cutout to route GPIO cables cleanly, or remove the top white lid to securely seat a Sense HAT while keeping the sides and bottom of the Pi fully protected.
• Effort/Requirements: Beginner Level. No screws or tools are

Package Includes:

• 1 x Case for Raspberry Pi (Raspberry PI board not included)

Frequently Asked Questions (FAQ)

• Does this case fit the Raspberry Pi 4 Model B?
  No, the Raspberry Pi 4 has a different port layout (Micro-HDMI and shifted USB/Ethernet). This is strictly for Pi 3, 2, and B+.
• Will it work with the newer Raspberry Pi 3 Model B+?
  Yes, it is fully compatible with the Pi 3 Model B+.
• How do I access the GPIO pins once assembled?
  You can either remove the top white lid, or easily pop off the modular side plate designed specifically for horizontal GPIO ribbon cable access.
• Is this case compatible with the Raspberry Pi Sense HAT?
  Yes, slim HATs like the Sense HAT fit beautifully underneath the removable top white lid, utilizing the pink layer as a bezel.
• Do I need tiny screws to put this together?
  No screws required. It utilizes a secure, 5-part friction and snap-fit design.
• How do I fit a HAT with tall/standard headers?
  You can remove the top two layers (white and pink) completely, or use pliers to clip the small alignment nub on the pink layer for a custom flush fit.
• Can I see the status LEDs through the case?
  Yes, there are light pipes. However, note that on the Raspberry Pi 3, the LEDs moved from their B+ position, so they may be partially obstructed.
• Can I use a cooling fan with this case?
  There are no dedicated fan mounts. To use a fan, you would need to run the case with the top white lid removed.
• What material is this enclosure made of?
  It is manufactured from high-grade, durable ABS plastic.
• Does the plastic block WiFi or Bluetooth signals on the Pi 3?
  No, ABS plastic is completely RF transparent and will not degrade your wireless connections.
• How do I route the Pi Camera (CSI) cable?
  The case features a dedicated, slim routing slot specifically for the CSI camera ribbon cable.
• Does the case slide around on a desk?
  No, it includes self-adhesive anti-slip rubber feet to keep your setup stable during prototyping.
• Can I wall-mount this enclosure?
  There are no built-in keyholes for wall mounting. You would need to use double-sided mounting tape or Velcro.
